Page 181
SECTION 4 - PLATFORM
3121617
600A/600AJ
181
FIGURE 4-7. SOFT TOUCH SYSTEM INSTALLATION (36IN/91.5CM DEPTH PLATFORMS) (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SOFT TOUCH SYSTEM INSTALLATIONS
0273824
Ref
6ft Platform
B
0272427
Ref
8ft Platform
E
1001108256
Ref
6ft/1.8m PLATFORM W/FALL ARREST
A
0273706
Ref
8Ft/2.4m Platform w/Fall Arrest
B
1
0100011
AR
Compound, Locking
2
0200048
2
Arm, Switch
3
0630462
8
Bolt, Carriage
4
0641414
8
Bolt 1/4in-20NC x 1-3/4in
5
Ref
Bolt Options:
5
0721005
4
Bolt #10-24NC x 5/8in
5
0731005
4
Bolt #10-32NF x 5/8in
6
Ref
Bumper Kits (Includes Corners and Enough Straight Material for
One Platform)
6
0940134
1
6ft Platform
6
0940103
1
8ft Platform
6
0940177
1
6ft Platform with Fall Arrest
6
0940133
1
8ft Platform with Fall Arrest
6
0940092
1
Bumper (Corner) Options:
6
Ref
6ft/8ft Platform without Fall Arrest
6
Ref
6ft/8ft Platform with Fall Arrest
6
0940094
AR
Bumper (12ft Length)
7
1060341
23 ft/7m
Cable, Electrical - 16/2
8
1060903
4
Wire Rope and Eyebolt Assembly
9
1702938
1
Decal - Soft Touch Override
10
3311401
8
Nut 1/4in-20NC
11
3311501
8
Nut 5/16in-18NC
12
Ref
Plate, Switch Strike Options:
12
3575359
2
6ft Platform
12
3574091
2
8ft Platform
13
4240099
7
Tie-Strap
14
4360057
2
Switch, Limit
15
4360387
1
Switch, Push Button
16
4420068
1
Tape, Adhesive
17
4460049
2
Connector, Strain Relief
18
4460234
7
Tie-Strap
19
4460425
1
Connector, Strain Relief
20
4751400
8
Flatwasher 1/4in Regular
21
4751500
AR
Flatwasher 5/16in Regular
22
4751800
8
Flatwasher 1/2in Regular
23
Ref
Rail, Soft Touch Options:
23
3641569
1
6ft Platform
23
4846673
1
8ft Platform
24
Ref
Soft-Touch Installation Kit Options (Not Shown) (Includes Items
2-23):
Ref
Note: May not be available for all machines depending on
existing options. Contact JLG Parts Dept before ordering.
24
1001121592
1
Kit - 6ft Platform without Fall Arrest
24
1001121593
1
Kit - 8ft Platform without Fall Arrest
