SECTION 7 - ELECTRICAL
256
600A/600AJ
3121617
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (SN 0300181175 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001107753
Ref
PLATFORM BOX HARNESS ASSEMBLY
D
19
4460866
1
Terminal, 19 Pin Connector
20
4460874
1
Connector - 35 Position (Natural)
21
4460875
1
Connector - 35 Position (Gray)
22
4460873
1
Connector - 35 Position (Black)
23
4460871
70
Socket, Female
24
4460464
7
Pin, Male (16 Gauge)
25
4460879
1
Terminal, Housing 2 Position
26
4460887
2
Terminal, (12 Gauge)
30
4460418
9
Connector - 6 Position
31
4460419
27
Terminal, Female
32
4120035
13
Base, Light
36
4460225
1
Plug, Male- 6 Position
37
4460227
30
Pin, Male
41
4460508
3
Pin, Male (12 Gauge)
43
4460434
2
Connector - 15 Position
44
2920129
13
Lamp, Indicator
47
4460905
26
Seal, Plug
1001159099
Ref
PLATFORM BOX ASSEMBLY COMPONENTS
B
103
0100048
AR
Grease, Dielectric
106
See Note
1
Footswitch Harness
106
1060918
8 ft/2.4m
Cable, Electrical - 18/3
106A
4460071
1
Connector, Strain Relief
136
4460428
2
Connector, Strain Relief
137
4460470
1
Nut, Terminal
138
4460471
1
Lockwasher, Terminal
139
4460708
2
Connector, Female - 15 Position
143
4922666
1
Harness, Analyzer Cable
2-B
143
4460226
4
Socket, Female (Not Shown - Located at J2)
143A
4460761
1
Connector, Female - 4 Position
143A
4460227
1
Pin, Male
145
1001107753
1
Harness, Platform Console Box (Includes Items 1-44)
147
1001139135
1
Platform Valve Harness Assembly
147A
4460226
7
Socket, Female
147B
4460891
6
Plug, Male - 2 Position
147B
1001116992
12
Socket, Female
Ref
BOOM CABLES INSTALLATION
Ref
Boom Cables Installation 600A
0270818
Ref
ANSI, ANSI Export, CSA &Japanese Specs without 7500W
Generator
6
0272624
Ref
ANSI, ANSI Export & CSA Specs with 7500W Generator
2
0275265
Ref
ANSI, ANSI Export & CSA Specs with Arctic Package without
7500W Generator
1
1001093436
Ref
ANSI, ANSI Export & CSA Specs with Arctic Package with
7500W Generator
2-A
0270819
Ref
CE Specs without 7500W Generator
6
0272626
Ref
CE & Japanese Specs with 7500W Generator
2
Ref
Boom Cables Installation 600AJ
1001165366
Ref
ANSI, ANSI Export, CSA & Japanese Specs without 7500W
Generator
A
