SECTION 2 - TURNTABLE
116 600A/600AJ 3121617
ITEM PART NUMBER QTY DESCRIPTION REV
123 4061010 1 Insulation Options:
123 1001160964 1 Insulation for Deutz D2011 Engine Machines (ANSI, ANSI
Export, CSA and Japanese Specs)
123 1001161027 1 Insulation with Noise Reduction for Deutz D2011 Engine
Machines (ANSI Export, Australian, CE and Japanese Specs)
123 1001160964 1 Insulation for Deutz TD2.9L4 Engine Machines
123 1001160964 1 Insulation for GM Engine Machines
1671216 Ref HOOD TANK SIDE
1001160003 Ref Hood for Deutz D2011 Engine Machines B
1001160190 Ref Hood for Deutz TD2.9L4 Engine Machines B
1001160003 Ref Hood for GM Engine Machines
201 0641606 4 Bolt 3/8in-16NC x 3/4in
202 Ref Hood, Tank Side Options:
202 1001160003 1 Hood for Deutz D2011 Engine Machines
202 1001160190 1 Hood for Deutz TD2.9L4 Engine Machines
202 1001160003 1 Hood for GM Engine Machines
203 2940088 1 Latch
204 3311005 2 Locknut #10-24NC
205 3911016 2 Screw #10-24NC x 1in
206 3960389 3 ft/0.9m Seal
207 3960438 4.5
ft/1.4m
Seal
208 3960462 5.5
ft/1.6m
Seal
209 4751000 2 Flatwasher #10 Regular
210 4751600 4 Flatwasher 3/8in Regular
211 1001151670 2 Hinge
1001152325 Ref NOISE REDUCTION INSTALLATION (DEUTZ TD2.9L4 ENGINE
MACHINES ONLY) A
301 0100011 AR Compound, Locking
302 0641606 5 Bolt 3/8in-16NC x 3/4in
303 2820078 1 Foam, Acoustical
304 2820082 1 Foam, Acoustical
305 2820083 1 Foam, Acoustical
306 3539988 1 Plate, Baffle
307 4751600 5 Flatwasher 3/8in Regular
