SECTION 3 - BOOM
160 600A/600AJ 3121617
FIGURE 3-6. VALVES AND SWITCHES INSTALLATION (BOOM MOUNTED)
ITEM PART NUMBER QTY DESCRIPTION REV
1001155267 Ref BOOM VALVES AND LIMIT SWITCHES INSTALLATION (ALL
SPECS) B
1 4641436 2 Valve, Manual 2-Way
2 4360578 2 Switch, Limit
3 3931430 6 Bolt, Socket Head 1/4in-20NC x 1-7/8in
4 0100011 AR Compound, Locking
5 0630427 2 Bolt, Special
6 3311801 3 Nut 1/2in-13NC
8 3310801 4 Nut #8-32NC
9 4751400 8 Flatwasher 1/4in Regular
10 3930828 4 Bolt, Socket Head #8-32NC x 1-3/4in
11 3931408 2 Bolt, Socket 1/4in-20NC x 1/2in
12 4460968 2 Connector, Strain Relief
13 1001155399 1 Cover, Switch
Ref CONTROL VALVES INSTALLATION (ALL SPECS)
1001152535 Ref Control Valves Installation 600A 2WS with Deutz D2011 and
GM Engines (SN 0300177361 through 0300181174) C
1001160038 Ref Control Valves Installation 600A 2WS with Deutz D2011 and
GM Engines (SN 0300181175 to Present) B
1001145379 Ref Control Valves Installation 600A 2WS with Deutz TD2.9L4
Engines (SN 0300177361 through 0300181174) C
1001164168 Ref Control Valves Installation 600A 2WS with Deutz TD2.9L4
Engines (SN 0300181175 to Present) B
1001152534 Ref Control Valves Installation 600A 4WS with Deutz D2011 and
GM Engines (SN 0300177361 through 0300181174) C
1001160039 Ref Control Valves Installation 600A 4WS with Deutz D2011 and
GM Engines (SN 0300181175 to Present) B
1001145720 Ref Control Valves Installation 600A 4WS with Deutz TD2.9L4
Engines (SN 0300177361 through 0300181174) D
1001164160 Ref Control Valves Installation 600A 4WS with Deutz TD2.9L4
Engines (SN 0300181175 to Present) B
1001152537 Ref Control Valves Installation 600AJ 2WS with Deutz D2011 and
GM Engines (SN 0300177361 through 0300181174) C
1001160068 Ref Control Valves Installation 600AJ 2WS with Deutz D2011 and
GM Engines (SN 0300181175 to Present) B
1001145719 Ref Control Valves Installation 600AJ 2WS with Deutz TD2.9L4
Engines (SN 0300177361 through 0300181174) D
1001164164 Ref Control Valves Installation 600AJ 2WS with Deutz TD2.9L4
Engines (SN 0300181175 to Present) B
1001152265 Ref Control Valves Installation 600AJ 4WS with Deutz D2011 and
GM Engines (SN 0300177361 through 0300181174) C
1001164170 Ref Control Valves Installation 600AJ 4WS with Deutz D2011 and
GM Engines (SN 0300181175 to Present) B
1001145721 Ref Control Valves Installation 600AJ 4WS with Deutz TD2.9L4
Engines (SN 0300177361 through 0300181174) D
1001160069 Ref Control Valves Installation 600AJ 4WS with Deutz TD2.9L4
Engines (SN 0300181175 to Present) B
101 0100011 AR Compound, Locking (SN 0300181175 to Present)
102 0630467 6 Screw 5/6-18 x 1/2 (SN 0300181175 to Present)
105 0641424 2 Bolt 1/4-20 x 3
106 0641606 2 Bolt 3/8-16 x 3/4 (SN 0300181175 to Present)
110 1670964 1 Cover (SN 0300181175 to Present)
113 3311405 2 Nut 1/4-20
