SECTION 2 - TURNTABLE
3121617
600A/600AJ
57
FIGURE 2-5. SWING DRIVE, TURNTABLE BEARING AND LOCK INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001152181
Ref
SWING DRIVE INSTALLATION
C
1
0100019
AR
Compound, Locking
2
3952020
1
Setscrew 5/8in - 11NC x 2-1/2in
3
0682218
4
Bolt 3/4in - 10NC x 2-1/4in Grade 8
4
3312002
1
Nut, Jam 5/8in - 11NC
5
3900293
1
Capscrew 1in x 1-1/4in
6
4071009
1
Shim
7
4740057
4
Flatwasher, Hardened
8
1001101060
1
Swing Hub Assembly (See SWING MOTOR/HUB ASSEMBLY for
Breakdown)
9
1001152234
1
Plate, Spacer
1001150391
Ref
TURNTABLE BEARING AND REMOTE LUBE INSTALLATION
C
101
0100019
AR
Compound, Locking
102
0440207
1
Bearing, Turntable
103
0682018
36
Bolt 5/8in - 11NC x 2-1/4in Grade 8
104
3020029
AR
Lubricant
105
4892000
36
Flatwasher 5/8in Hardened
106
0100011
AR
Compound, Locking
107
1001149927
1
Hose (Includes Grease Fitting and Adapter Fittings)
0255410
Ref
TURNTABLE LOCK INSTALLATION (MACHINES WITH DEUTZ
D2011 AND GM ENGINES)
B
201
4844958
1
Pin
202
3421565
1
Pin, Snap
203
3760170
2
Ring, Quick Release
204
1260017
9 in/23cm
Chain
1001137885
Ref
TURNTABLE LOCK INSTALLATION (MACHINES WITH DEUTZ
TD2.9L4 ENGINES)
A
301
1260017
9 in/23cm
Chain
302
3760170
2
Ring, Quick Release
303
1001137896
1
Pin
304
1001145292
1
Pin, Snap
