SECTION 2 - TURNTABLE
3121617 600A/600AJ 131
ITEM PART NUMBER QTY DESCRIPTION REV
Items 401-410 for Breakdown)
Ref DECAL INSTALLATION
0272435 Ref 60Hz (ANSI and ANSI Export Specs) B
0272589 Ref 50Hz (ANSI Export, Australian and CE Specs) A
201 1705460 2 Decal - SkyPower
202 1705374 1 Decal - 240V - 60Hz (60Hz Spec Only)
203 Ref Decal - 240V - 3 Phase Options:
203 1705375 1 60Hz (ANSI and ANSI Export Specs)
203 1705461 1 50Hz (ANSI Export, Australian and CE Specs)
204 Ref Decal, Hazardous Voltage Options:
204 1705387 3 60Hz (ANSI and ANSI Export Specs)
204 1705489 3 50Hz (ANSI Export, Australian and CE Specs)
Ref ELECTRICAL DIAGRAM COMPONENTS
1001112586 Ref Deutz D2011 Engines A
1001157770 Ref Deutz TD2.9L4 A
301 Ref Generator Harness Options (See ELECTRICAL SECTION for
Breakdown):
301 1001112587 1 Deutz D2011 Engines A
301 1001119968 1 Deutz DT2.9L4 Engines A
301A 4460374 2 Plug, Sealed Relay (Deutz D2011 Engines Only)
301A 4460375 7 Terminal (Deutz D2011 Engines Only)
301B 4460967 1 Plug, Male - 3 Position
301B 4460465 3 Socket, Female
301C Ref Component Options:
301C 2400060 1 Fuseholder (Deutz D2011 Engines) (Not Shown)
301C 2400064 1 Fuse - 5 Amp (Deutz D2011 Engines) (Not Shown)
301C 1001117078 1 Fuseholder (Includes Fuse and Cap) (Deutz DT2.9L4
Engines) (Not Shown)
301C See Note 1 Fuse - 5 Amp (Deutz DT2.9L4 Engines) (Not Shown)
(Note: Use 1001117078 Assembly or Purchase Fuse
Locally)
301C 1001096134 1 Cover, Fuseholder (Deutz DT2.9L4 Engines) (Not Shown)
304 4922641 1 Switch Harness
1001121340 Ref TERMINAL BLOCK ASSEMBLY (DEUTZ D2011 ENGINES ONLY) A
401 70002818 2 Marker Strip #1
402 70002819 4 Marker Strip #2
403 70002820 2 Marker Strip #3
404 70002821 2 Marker Strip #4
405 70002822 4 Marker Strip #5
406 70002823 1 Terminal, End Barrier
407 70002824 2 Terminal, End Block
408 70002825 7 Terminal, Block
409 70002826 2 Terminal, Cross Connector Jumper
410 3641533 1 Rail, Relay
