SECTION 1 - FRAME
3121617 600A/600AJ 11
FIGURE 1-1. AXLE INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
Ref AXLE INSTALLATIONS (8FT/2.4M WIDE MACHINES)
1001148168 Ref Oscillating Axle without Tow Package C
1001152448 Ref Oscillating Axle without Tow Package (With Turf Tire) B
1001148170 Ref Oscillating Axle with Tow Package C
1001148169 Ref Fixed Axle Machines C
1 0100011 AR Compound, Locking
2 0641814 8 Bolt 1/2in-13NC x 1-3/4in
3 0642012 1 Bolt 5/8in-11NC x 1-1/2in
4 0961950 2 Bearing
5 1684465 2 Axle Lockout Cylinder Assembly (Oscillating Axle Only) (See
CYLINDER SECTION for Breakdown)
6 3423184 1 Pin
7 3841258 1 Keeper, Pin
8 4740158 1 Thrustwasher (1/4in Thick)
9 Ref Axle Weldment Options:
9 1001148171 1 Machines without Tow Package
9 1001151966 1 Machines without Tow Package (With Turf Tire)
9 1001148172 1 Machines with Tow Package
10 4891800 8 Flatwasher 1/2in Hardened
11 0100038 AR Primer, Locking
12 4740229 AR Thrustwasher (1/8in Thick)
13 4071101 AR Shim
25 3539877 2 Plate, Stop (Fixed Axle Only)
27 3931840 Capscrew 1/2in-13NC x 2-1/2in
28 4070944 6 Shim (.06) (Fixed Axle Only)
29 4070945 2 Shim (.25) (Fixed Axle Only)
Ref AXLE INSTALLATIONS (7FT/2.1M WIDE MACHINES)
0274047 Ref Oscillating Axle without Tow Package B
0274256 Ref Oscillating Axle with Tow Package B
0274054 Ref Fixed Axle B
101 0100011 AR Compound, Locking
102 Ref Axle Weldment Options:
102 0280171 1 Machine without Tow Package
102 0280185 1 Machine with Tow Package
103 0641814 8 Bolt 1/2in-13NC x 1-3/4in
104 0642012 1 Bolt 5/8in-11NC x 1-1/2in
105 0961950 2 Bearing
106 1684465 2 Axle Lockout Cylinder Assembly (Oscillating Axle Only) (See
CYLINDER SECTION for Breakdown)
107 3422592 1 Pin
108 3841258 1 Keeper, Pin
109 4740158 1 Thrustwasher (1/4in Thick)
110 4891800 8 Flatwasher 1/2in Hardened
111 0100038 AR Primer, Locking
113 0641816 2 Bolt 1/2in-13NC x 2in
115 3539877 2 Plate, Stop (Fixed Axle Only)
116 4740542 2 Spacer (Fixed Axle Only)
