SECTION 5 - CYLINDER
3121617 600A/600AJ 193
FIGURE 5-4. LIFT CYLINDER ASSEMBLY - JIB
ITEM PART NUMBER QTY DESCRIPTION REV
Ref JIB LIFT CYLINDER ASSEMBLY - 600AJ ONLY
1683609 Ref Jib Lift Cylinder Assembly 600AJ without Arctic Package I
1001128792 Ref Jib Lift Cylinder Assembly 600AJ with Arctic Package A
1 1684089 1 Barrel
1A 0962336 2 Bushing
2 1683053 1 Head
3 3760368 1 Ring, Washer
4 3931516 8 Capscrew, Socket Head 5/16in-18NC x 1in
5 1684090 1 Rod
5A 0962336 2 Bushing
6 4640509 2 Cartridge, Valve
6 2900792 2 Seal Kit - 4640509 Valve
8 2220883 2 Plug, O-Ring #4
9 2220885 1 Plug, O-Ring #6
10 3480210 1 Piston
11 0961893 1 Bushing, Tapered
12 4100100 1 Spacer, Tube
14 See Note 2 Seal (Note: Use Item 51)
15 See Note 2 Ring, Lock (Note: Use Item 51)
16 See Note 2 O-Ring (Note: Use Item 51)
17 See Note 2 Ring, Back-up (Note: Use Item 51)
18 See Note 1 O-Ring (Note: Use Item 51)
19 See Note 1 Ring, Back-up (Note: Use Item 51)
20 See Note 1 Seal, Rod (Note: Use Item 51)
21 See Note 1 Wiper (Note: Use Item 51)
22 See Note 1 Ring, Wear (Note: Use Item 51)
23 0100011 AR Compound, Locking
24 0100038 AR Primer, Locking
26 0630534 3 Bolt #10 - 24NC x 1in
51 Ref Seal Kit Options (Includes Items 14-22):
51 2901303 1 Seal Kit Without Arctic Package
51 1001138795 1 Seal Kit With Arctic Package
