SECTION 2 - TURNTABLE
80
600A/600AJ
3121617
FIGURE 2-9. GM ENGINE INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
GM ENGINE INSTALLATION
1001114640
Ref
Machines without Arctic Package
B
1001114642
Ref
Machines with Arctic Package:
A
1
0100011
AR
Compound, Locking
2
0100020
AR
Sealant, Pipe
3
0100048
AR
Grease, Dielectric
4
0400075
1
Battery (Wet)
5
0641416
2
Bolt 1/4in-20NC x 2in
6
0641505
2
Bolt 5/16in-18NC x 5/8in
7
0641506
2
Bolt 5/16in-18NC x 3/4in
8
0641608
1
Bolt 3/8in-16NC x 1in
9
0641808
1
Bolt 1/2in-13NC x 1in
10
0642010
1
Bolt 5/8in-11NC x 1-1/4in
11
1320022
4
Clamp, Fuel Line
12
1320323
1
Clamp
13
1701542
1
Decal, Gas (Not Shown)
14
1701543
1
Decal, LPG (Not Shown)
15
2180418
1
Fitting, Straight
16
2220005
1
Fitting, Straight
17
2220064
1
Fitting, Adapter
18
2221176
1
Fitting, 90
19
Ref
Fluid, Anti-Freeze Options (Not Shown):
19
2300004
2.7 gal.
Machines without Arctic Package
19
2300041
2.7 gal.
Machines with Arctic Package
20
2720392
1
Hose, LP
21
2720496
1
Hose, Hi Pressure Fuel Line
22
2720566
1
Hose (6in/15cm Length)
23
2720598
1
Hose (92in/234cm Length)
24
3290405
1
Locknut M4 x 0.7
25
3290505
1
Locknut M5 x 0.8
26
3311505
2
Locknut 5/16in-18NC
27
3422448
1
Pin
28
3790012
1
O-Ring (Not Shown - Located in Console Box)
29
3841143
1
Keeper
30
4360336
1
Switch, Toggle (Not Shown - Located in Console Box)
31
4569385
1
Tube, Fuel Line
32
4711400
2
Flatwasher 1/4in Thin
33
4711500
6
Flatwasher 5/16in Thin
34
4751500
2
Flatwasher 5/16in Regular
35
4752000
1
Flatwasher 5/8in Regular
36
88521205
2
Locknut 5/16in-18NC
37
91401281
1
Angle, Battery Hold Down
38
1001091587
6.25
ft/1.9m
Hose, Fuel Line
39
1001093382
2
Bolt, Battery Hold Down
Ref
Note: Arctic Package Items 41 - 53 Not Shown - Used on
Arctic Machines Only
41
1060625
1
Cable, Immersion Heater (Located on bottom of Hydraulic Oil
Tank)
42
1060626
1
Cord, 3 Way Extension (Located on Left Front of Engine)
