SECTION 5 - CYLINDER
3121617
600A/600AJ
207
FIGURE 5-10. TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
TELESCOPE CYLINDER ASSEMBLY - MAIN BOOM
1683307
Ref
Telescope Cylinder Assembly 600A
6-G
1683317
Ref
Telescope Cylinder Assembly 600AJ
6-G
1
Ref
Barrel Options:
1
1683308
1
Barrel 600A
1
1683318
1
Barrel 600AJ
2
Ref
Rod Options:
2
1684308
1
Rod 600A
2
1684310
1
Rod 600AJ
3
3480212
1
Piston
4
1683054
1
Head
5
4566425
1
Spacer
6
0961896
1
Bushing, Tapered
7
Ref
Plate, Wear Pad Mounting Options:
7
3538771
1
Plate, Wear Pad Mounting 600A
7
3538247
1
Plate, Wear Pad Mounting 600AJ
8
4640862
1
Valve Block Assembly (Note: No Service Parts Available -
Replace Complete Assembly)
9
2220885
2
Plug, O-Ring
10
3931516
8
Capscrew, Socket Head 5/16in-18NC x 1in
11
3931448
4
Capscrew, Socket Head 1/4in-20NC x 3in
12
2901861
2
Ring, Wear
13
2901861
1
Seal
14
2901861
1
O-Ring
15
2901861
1
O-Ring
16
2901861
1
Ring, Wear
17
2901861
1
O-Ring
18
2901861
1
Ring, Back-up
19
2901861
1
Seal, Rod
20
2901861
1
Wiper
21
2901861
2
Ring, Back-up
22
0100038
AR
Primer, Locking
23
0100011
AR
Compound, Locking
24
3340608
2
Pad, Wear
25
0641604
4
Bolt 3/8in-16NC x 1/2in
26
4751600
4
Flatwasher 3/8in Regular
28
0630535
3
Bolt 1/4in-20NC x 1-1/8in
51
2901861
1
Seal Kit (Includes Items 12-21)
