JLG 600A_AJ Parts Manual User Manual
Page 120
SECTION 2 - TURNTABLE
120
600A/600AJ
3121617
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
9
0641772
1
Bolt 7/16in-14NC x 9in
10
4751600
6
Flatwasher 3/8in Regular
11
2860012
1
Key, Woodruff
12
3311605
1
Locknut 3/8in-16NC
13
3311705
1
Locknut 7/16in-14NC
14
3740080
1
Relay
16
0641508
1
Bolt 5/16in-18NC x 1in
17
4751500
AR
Flatwasher 5/16in Regular
20
0721006
AR
Bolt #10-24NC x 3/4in
21
3311005
AR
Locknut #10-24NC
22
4751000
AR
Flatwasher #10 Regular
25
4360336
1
Switch, Toggle (Not Shown - Located at Platform)
26
4740397
1
Bushing (Not Shown - Located at Platform)
27
4060802
1
Guard, Switch (Not Shown - Located at Platform)
28
3252507
1
Decal - 220V - 50/60Hz (Not Shown - Located on Turntable)
29
2820031
4 in/10cm
Heatshrink (Not Shown - Located at Platform)
30
3251102
1
Decal (Not Shown - Located at Platform)
Ref
Note: Items 32-43 Used on ANSI Export, Australian and CE
Specs Only.
32
0641404
1
Bolt 1/4in-20NC x 1/2
33
3252507
2
Decal - 220V - 50Hz
Ref
Note: One Decal Not Shown - Located on the Inside of
Platform Rail.
34
3290505
1
Locknut M5 x 0.8mm
35
4031608
1
Bolt M5 x 20mm
36
4240018
1
Tie Strap (Not Shown)
37
4420060
1
Tape, Double Coated Acrylic Foam
38
4460968
3
Connector, Strain Relief
39
4811600
1
Flatwasher M5
40
1001099869
1
Box, Junction
42
Ref
Light Red Options:
42
1001100233
1
125 Vac
42
1001100234
1
250 Vac
43
0962449
1
Bushing
2902085
1
Kit, Powermite Generator Mounting
