SECTION 3 - BOOM

162

600A/600AJ

3121617

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

306

7023912

1

Valve, Relief

306

7012967

1

Seal Kit - 7023912 Valve

307

7017452

1

Valve, Solenoid (Jib)

307

7017402

2

Seal Kit - 7017452 Valve

308

7017452

1

Valve, Solenoid (Platform Level)

308

7017402

1

Seal Kit - 7017452 Valve

309

7017452

1

Valve, Solenoid (Rotator)

309

7017402

2

Seal Kit - 7017452 Valve

310

70002386

6

Coil

311

70002064

2

Plug, Orifice (Not Shown)

312

7017406

2

Plud (Not Shown)

1001152564

Ref

CONTROL VALVE ASSEMBLY - 600A

C

401

7012965

1

Valve, Flow

401

7012953

1

Seal Kit - 7012965 Valves

402

7012914

2

Valve, Catridge

402

7012918

2

Seal Kit - 7012914 Valve

403

7023911

1

Valve, Relief

403

7012967

1

Seal Kit - 7023911 Valve

404

7023912

1

Valve, Relief

404

7012967

1

Seal Kit - 7023912 Valve

405

7017452

1

Valve, Solenoid (Platform Level)

405

7017402

1

Seal Kit - 7017452 Valve

406

7017452

1

Valve, Solenoid (Rotator)

406

7017402

2

Seal Kit - 7017452 Valve

407

70002386

4

Coil

408

70002064

2

Plug, Orifice (Not Shown)

409

7017406

2

Plug (Not Shown)
