SECTION 1 - FRAME
3121617 600A/600AJ 23
ITEM PART NUMBER QTY DESCRIPTION REV
108 0962005 2 Bushing
109 0962272 4 Bushing
110 0962292 2 Bushing
111 0962348 1 Bushing
112 1120460 2 Cap, Hub
113 1684418 2 Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
114 2780276 2 Hub
114A 0630490 18 Stud, Wheel (9 Per Hub)
115 2980125 1 Pivot
116 3300106 18 Nut, Wheel
117 3323403 2 Nut, Slotted 1-1/2in-12NF
118 3340966 2 Pad
119 3422327 1 Pin
120 3422426 2 Pin
121 3422429 AR Pin
122 3422430 2 Pin
123 3422813 1 Pin
124 3422848 1 Pin
125 3423175 2 Kingpin
126 3451010 4 Pin, Cotter 5/16in x 2-1/2in
127 3575716 1 Link
128 3841143 6 Keeper
129 3841263 1 Tie-Rod
130 3960098 2 Seal
131 4071059 2 Shim
132 4130413 1 Spindle
133 4130414 1 Spindle
134 4740016 2 Flatwasher, Hardened
135 4740111 4 Thrustwasher
136 4740155 2 Thrustwasher
137 4740184 1 Flatwasher, Special
138 0100011 AR Compound, Locking
139 3313403 2 Nut, Slotted 1-1/2in-6NC
