SECTION 2 - TURNTABLE
3121617 600A/600AJ 111
FIGURE 2-17. ENGINE TRAY JACK INSTALLATIONS (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref ENGINE TRAY JACK INSTALLATION
0255880 Ref Machines with Deutz D2011 Engines 6-H
1001137891 Ref Machines with Deutz DT2.9L4 Engines B
0255880 Ref Machines with GM Engines 6-H
1 3537445 1 Bracket
2 Ref Bracket Options:
2 4845163 1 Machines with Deutz D2011 Engines
2 1001137892 1 Machines with Deutz DT2.9L4 Engines
2 4845163 1 Machines with GM Engines
3 2840018 1 Hydraulic Jack Assembly
3A Ref Burr Manufacturing Brand
3B Ref Hammerblow Corp and Cequent Brands
3C Ref Handle Options:
3C 7016374 1 Burr Manufacturing Brand
3C 7024598 1 Hammerblow Corp and Cequent Brands
3D 7016322 1 Wiper (Burr Manufacturing Brand Only)
4 0962051 2 Bushing, Flanged
5 3430816 1 Pin, Clevis
6 4891800 1 Flatwasher 1/2in Hardened
7 4711800 AR Flatwasher 1/2in Thin
8 3450404 1 Pin, Cotter 1/8in x 1in
9 0641609 4 Bolt 3/8in-16NC x 1-1/8in
10 3311605 4 Locknut 3/8in-16NC
11 4891600 4 Flatwasher 3/8in Hardened
12 0641810 4 Bolt 1/2in-13NC x 1-1/4in
14 Not Required 0 Not Required
15 1380147 1 Clip, Spring
22 3910608 2 Screw #6-32NC x 1in
23 3310601 2 Nut #6-32NC
24 4770600 2 Starwasher #6
