SECTION 4 - CONTROL COMPONENTS
3121136
– JLG Lift –
4-13
Table 4-1. DVL/DVSP Ground Control Module - Field Programmable Settings and Factory Preset.
Level-2: Service Level Settings
On LCD Display:
YES =
!
HIGH =
↑
Level-3: Operator Level Settings
NO =
✕
LOW =
↓
LEVEL
PROGRAMMABLE ITEM
FACTORY
PRESET
SETTING RANGE
2
Back to Main
–
Return to Programming Menu
3
Set Language
NOTE: There are two production modules available at this
time, one for North/South American and European
Languages, and one for Asian Languages.
1
1 - English
6 - Italian
2 - German
7 - Swedish
3 - Dutch
8 - Brazilian Portuguese
4 - French
9 - Finnish
5 - Spanish
2
1 - English
3 - Japanese
2 - Chinese
2
Set Maximum Lift Up Speed
100%
0 - 100%
2
Set Maximum Lift Down Speed
100%
0 - 100%
2
Zero the On-Board Tilt Sensor
NO
YES/NO
2, 3
Set Sleep Time
5 MINS
0 - 60 MINS
2
Set Polarity Of Left Pot Hole Input 1
2
0 - Disabled / 1 - LOW / 2 - HIGH
2
Set Polarity Of Right Pot Hole Input 2
2
0 - Disabled / 1 - LOW / 2 - HIGH
2
Set Polarity Of Up Limit/elevation Input
HIGH
HIGH/LOW
2
Set Polarity Of Charger Inhibit
HIGH
HIGH/LOW
2, 3
Set Polarity Of The Keypad Code
LOW
HIGH/LOW
2
Set Polarity Of Ancillary Input 1
LOW (a)
HIGH/LOW
2
Set Polarity Of Ancillary Input 2
LOW (b)
HIGH/LOW
2, 3
Enable Detection Of Horn Open Circuit
NO (c)
YES/NO
2, 3
Enable Detection Of Beacon Open Circuit
NO (c)
YES/NO
2
Enable Obstruction Sensor System (OSS)
NO
YES/NO
2
Enable Detection Of Aux. #1 Open Circuit
NO (d)
YES/NO
2
Enable Detection Of Aux #2 Open Circuit
NO (d)
YES/NO
2
Acceleration (Platform Lowered)
40
1 - 100
2
Deceleration (Platform Lowered)
45
1 - 100
2
Turn Acceleration (Platform Lowered)
30
1 - 100
2
Turn Deceleration (Platform Lowered)
30
1 - 100
2
Maximum Forward Speed (Platform Lowered)
100
1 - 100
2
Minimum Forward Speed (Platform Lowered)
30
1 - 100
2
Maximum Reverse Speed (Platform Lowered)
100
1 - 100
2
Minimum Reverse Speed (Platform Lowered)
20
1 - 100
2
Maximum Turn Speed (Platform Lowered)
30
1 - 100
2
Minimum Turn Speed (Platform Lowered)
10
1 - 100
2
Minimum Forward Speed (Platform Elevated)
20
1 - 100
2
Minimum Reverse Speed (Platform Elevated)
20
1 - 100
2
Maximum Turn Speed (Platform Elevated)
5
1 - 100
2
Motor Compensation
90 mOhms
0 - 500 mOhms
3
Forward Alarm Disable
NO
YES/NO
3
OSS Diagnostic
NO
YES/NO
2
Mode Select Delay (Drive/Lift Mode active before timeout)
5 Sec.
0 - 60 Seconds
2
Invert Lift Direction
X
YES/NO
2
Lift Lock Delay
5 Sec.
0 - 60 Seconds
Notes: (a) DVSP Models equipped with stock-picker platform and mid-gate interlock (drive inhibit) switch are factory preset to HIGH.
(b) DVSP Models equipped with 12 ft. lift-limit-switch option are factory preset to HIGH.
(c) DVSP Models this feature is standard equipment and are factory preset to YES.
(d) This circuit is currently unused on both DVL/DVSP Models.
