SECTION 6 - TROUBLESHOOTING

6-26

– JLG Lift –

3121136

Code 33 - Both PHP Bars - UP

Code 38 - Battery Voltage Low - Warning Level 2 - Two (2) LED/LCDs lit

To maximize battery life, it is recommended that the factory supplied batteries be charged continuously for a minimum of 4
hours or until 8 bars are lit on the ground station LCD Display before operating the machine. When drained to Warning Level
2, batteries must be charged until 8 bars are lit on the ground station LCD display to clear the fault code. Failure to do so,
will result in a fault code 39.

Code 39 - Battery Voltage Low - Warning Level 3 - One (1) LED/LCDs lit

To maximize battery life, it is recommended that the factory supplied batteries be charged continuously for a minimum of 4
hours or until 8 bars are lit on the ground station LCD Display before operating the machine. When drained to Warning Level
1, batteries must be charged until 8 bars are lit on the ground station LCD display to clear the fault code.

Table 6-34. Code 33 - Both PHP Bars - UP

STEP

ACTION

SPEC

YES

Perform steps in Code 2, Left PHP Bar UP then, Code 3, Right PHP
Bar UP. Do either of these steps correct the problem?

—

Done

Go to Step 2

Perform steps in Table 6-5 - Machine In Drive Speed Cut-Back (Tur-
tle) Mode All The Time, of this section.

—

Done

Consult Factory
