SECTION 1 - MACHINE SPECIFICATIONS
1-2
– JLG Lift –
3121136
1.1
CAPACITIES
System Voltage
All Models – 24 Volt DC
Hydraulic System
All Models – 5 qts. U.S. (4.7 L)
Drive Motor GearBox (gear oil)
All Models – 6 oz. (175cc)
1.2
COMPONENT DATA
Hydraulic Pump/Pump Motor Assembly
Pump Motor - 24 Volt DC motor, Standard Duty
Pump Displacement –
DVL/DVSP – .098 cu. in./rev. (1.6cc/rev.)
Pump Output (Max.) –
DVL/DVSP - 1.20 gpm @ 2200 psi @ 23.5 volts and 105
amps @ 45 centistrokes (200 SSU)
Reservoir Capacity –
DVL/DVSP - 1 Gallon (3.78 L)
Rear Wheel Drive Motors
Drive Motors -
1/2 HP, 24 Volt DC, Variable
Right Angle, Sealed Gear Box, 40:1 ratio
Brake Shaft and Drive Shaft - Integral to Motor
Parking Brake (must be released for pushing)
Batteries/Battery Charger
Batteries (2) – 12 Volt / 100 Amp Hour –
Deep Cycle Marine - RV
Weight – 65.7 lb. (29.8 Kg) - Per Battery
Battery Charger –
Microprocessor Controlled/SCR Circuit Monitor
120/240 Volt A.C. Selectable / 50/60 Hz input
24 volt, 20 amp output - with 2 amp finish
Reset Circuit Breaker
Automatic Charge Circuit
Plug Interlock Circuit
Wet/VRLA Battery Switch
NOTE: The batteries on DVL/DVSP machines require
approximately five (5) hours to fully charge when
drained to LOW BATTERY VOLTAGE warning on the
Ground Control Module LCD display.
1.3
PERFORMANCE DATA
Platform Capacities
Standard -
15DVL - 500 lb. (230kg)
20DVL - 350 lb. (160kg)
StockPicker - 15DVSP - 500 lb. (230kg)
20DVSP - 400 lb. (180kg)
Extendible -
15DVL/ 15DVSP - 500 lb. (230kg)
20DVL Series - 350 lb. (160kg)
Molded -
15DVL/15DVSP - 500 lb. (230kg)
20DVL Series - 350 lb. (160kg)
NOTE: Distribute weight evenly in platform when loading.
Reference the capacity decal on the machines’ decal
billboard mounted on mast.
Platform Size
Standard - 26in.-W x 26 in.-L (66cm) x (66cm)
Stockpicker - 28in.-W x 48in.-L (71cm x 122cm)
Extendible - 26in.-W x 49in.-L (66cm x 124cm)
Moulded - 25in.-W x 26in.-L (64cm x 66cm)
Machine Height (platform stowed)
DVL/DVSP - 78 in. (198cm) height
Base Footprint
DVL/DVSP - 29.25in.-W x 52in.-L (74cm) x (132cm)
1.4
TORQUE REQUIREMENTS
When maintenance becomes necessary or a fastener has
loosened, refer to the applicable Torque Chart in this section
of the manual, to determine proper torque values.
