SECTION 2 - TURNTABLE
88
1500SJ
3121263
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
304H
Not Available
4
Capscrew M10 x 20-8.8 (Purchase p/n 7024906)
304J
7024080
2
Seal (Purchase p/n 7024906)
304K
7024081
1
O-Ring (Purchase p/n 7024906)
304L
Not Available
1
Ring, Retaining (Purchase p/n 7024906)
304M
7024910
1
O-Ring (Purchase p/n 7024906)
304N
7024005
1
Plate, Wear (Purchase p/n 7024906)
304P
Not Available
1
Pin, Cylinder (Purchase p/n 7024906)
305
7024068
1
Control Module (Prior to SN 0300187742)
305
See Note
1
Control Module (Note: Not Available at Time of Printing) (SN
0300187742 to Present)
305A
7024084
1
Valve Body, Lever and Internal Components
305B
7024083
2
Coil, Solenoid
305C
Not Available
2
Spacer, Coil (Purchase p/n 7024068)
305D
7024085
1
Gasket
305E
Not Available
1
Cover (Purchase p/n 7024068)
305F
Not Available
1
Spring, Draw (Purchase p/n 7024068)
305G
7024086
1
Gasket
305H
Not Available
4
Capscrew M6 x 65-8.8 (Purchase p/n 7024068)
305J
Not Available
1
Capscrew M6 x 45-8.8 (Purchase p/n 7024068)
305K
Not Available
8
Capscrew M5 x 10-8.8 (Purchase p/n 7024068)
305L
7024087
1
O-Ring
305M
7024088
2
O-Ring
305N
7024089
2
Cup, Spring
305P
Not Available
2
Pin, Cylinder (Purchase p/n 7024068)
305R
70002569
2
Nut, Coil
310
Not Available
1
Housing
313
Not Available
2
Pin, Dowel
314
Not Available
1
Pin, Cylinder
320
Not Available
1
Screw 7/8-14NF (Front Drive Pump Only)
321
Not Available
1
Screw 9/16-18NF
322
Not Available
1
Screw 7/16-20NF
324
Not Available
1
Screw M10 x 1
327
Not Available
1
Pin, Double Break-Off
328
7018936
2
Orifice
331
Not Available
2
Pin, Clamping
333
Not Available
1
Screw, Locking M14
341
7024069
1
O-Ring
