SECTION 5 - CYLINDER
3121263 1500SJ 227
FIGURE 5-3. LEVEL (JIB) CYLINDER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
Ref JIB LEVEL CYLINDER ASSEMBLIES
1001118142 Ref Without Cold Weather Plus Package B
1001139998 Ref With Cold Weather Plus Package A
1 0100011 AR Compound, Locking
2 0630535 8 Bolt 1/4-20NC x 1-1/8
3 0961897 1 Bushing, Tapered
4 2220885 2 Plug, O-Ring
5 2220886 1 Plug, O-Ring
6 3932032 3 Capscrew 5/8-11NC x 2
7 4566667 1 Spacer
8 4640999 1 Cartridge, Holding Valve (Non Vented)
8 2900792 1 Seal Kit - 4640999 Cartridge Valve
9 4641248 1 Cartridge, Counterbalance Valve (Non Vented)
9 See Note 1 Seal Kit - 4641248 Cartridge Valve (Note: Not Available for
Purchase)
10 1001118143 1 Barrel Weldment
10A 0961950 2 Bushing
11 1001118145 1 Rod Weldment
11A 0961950 2 Bushing
12 1001118148 1 Head
13 1001118149 1 Piston
14 1001118177 1 Ring, Washer
100 Ref Seal Kit Options (Includes Items 101-109):
100 1001119647 1 Without Cold Weather Plus Package
100 1001139994 1 With Cold Weather Plus Package
101 See Note 3 Ring, Wear (Note: Use Item 100)
102 See Note 2 Ring, Back-up (Note: Use Item 100)
103 See Note 1 O-Ring (Note: Use Item 100)
104 See Note 1 O-Ring (Note: Use Item 100)
105 See Note 1 Seal (Note: Use Item 100)
106 See Note 1 Wiper, Rod (Note: Use Item 100)
107 See Note 2 Seal (Note: Use Item 100)
108 See Note 2 Ring, Guide (Note: Use Item 100)
109 See Note 1 Ring, Back-up (Note: Use Item 100)
