SECTION 3 - BOOM
168 1500SJ 3121263
ITEM PART NUMBER QTY DESCRIPTION REV
34 1001119991 1 Pin
35 1001119998 1 Pin
36 1001120000 2 Pin
37 1001120014 1 Shim 11Ga
38 1001120015 1 Shim 18Ga
39 1001120037 1 Bearing, Flange
40 1001120038 1 Bearing
41 1001120039 1 Bearing
1001119111 Ref JIB BOOM ASSEMBLY K
101 0100011 AR Compound, Locking
102 0641636 2 Bolt 3/8-16NC x 4-1/2
103 0681836 4 Bolt 1/2-13NC x 4-1/2 (Grade 8)
104 0811607 26 Screw 3/8-16NC x 7/8
105 0811608 8 Screw 3/8-16NC x 1
106 0961950 2 Bushing
107 3311608 8 Nut, Flange 3/8-16NC
108 3340881 10 Pad, Wear
109 3423161 2 Pin
110 3575889 1 Plate
111 3760351 4 Ring, Retaining
112 3900283 8 Screw, Buttonhead 3/8-16NC x 3/4
113 4070897 10 Pad, Wear
114 4070898 10 Pad, Wear
115 4071039 2 Shim 18Ga
116 4071040 2 Shim 11Ga
117 1001129961 2 Pad, Wear
118 4751600 2 Flatwasher 3/8 Regular
119 4891800 4 Flatwasher 1/2 Hardened
120 1001118663 1 Jib Telescope Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
121 1001119413 1 Boom, Jib Fly
122 1001119414 1 Boom, Jib Base
123 Ref Power Track Assembly
Ref Note: Original Equipment Power Track may have been
replaced with Service Replacement. Visually identify
component before ordering replacement parts.
123 1001134180 1 Power Track Assembly (was p/n 1001119544) (Prior to SN
0300155403)
123 1001134180 1 Power Track Assembly (SN 0300155403 to Present)
123 Ref Repair Section Options (Includes links, cross bars and
mounting hardware):
123 70003155 AR Repair Section for 1001119544 Power Track
123 70003923 AR Repair Section for 1001134180 Power Track
123 70003156 1 Mounting Bracket Repair Kit Options (Includes mounting feet for
both ends of power track and attaching hardware):
123 70003156 1 Bracket Kit for 1001119544 Power Track
123 70003924 1 Bracket Kit for 1001134180 Power Track
124 1001119654 1 Tube, Push
125 1001119668 1 Support, Power Track
126 1001119710 1 Shim, Push Tube
127 1001119714 2 Pad, Push Tube
128 88662523 10 Nut, Retainer
1001143928 1 Jib Wear Pad Kit (Includes Items 4, 5, 12, 25, 104, 108 & 113-117)
