SECTION 1 - FRAME
3121263
1500SJ
15
FIGURE 1-3. TIRE AND WHEEL DRIVE INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
WHEEL DRIVE INSTALLATION
0275685
Ref
With Bonfiglioli Drive Hub
B
1001104324
Ref
With Reggiana Riduttori Drive Hub
A
1
0100019
AR
Compound, Locking
3
0701617
48
Bolt M16 x 45mm (12 Per Wheel)
4
4892000
48
Flatwasher 5/8in Hardened (12 Per Wheel)
Ref
HUB AND MOTOR ASSEMBLY
2780286
Ref
With Bonfiglioli Drive Hub
C
1001104315
Ref
With Reggiana Riduttori Drive Hub
A
101
Ref
Drive Hub Assembly Options:
Ref
Note: Various brands used. When replacing complete hub,
note that all 4 hubs must be the same brand.
Ref
Note: Various brands used. Identify brand before ordering
replacement parts.
101
1001093243
4
Bonfiglioli Hub (was p/n 2780290) (See DRIVE HUB
ASSEMBLY - BONFIGLIOLI for Breakdown)
101
1001104325
4
Reggiana Riduttori Hub (See DRIVE HUB ASSEMBLY -
REGGIANA RIDUTTORI for Breakdown)
102
3160339
4
Drive Motor Assembly (See DRIVE MOTOR ASSEMBLY for
Breakdown)
Ref
TIRE AND WHEEL INSTALLATIONS
0271852
Ref
Foam-Filled Tires
B
1001115961
Ref
Solid Tires
A
Ref
Note: Assemblies may require ballast/foam filling to
manufacturer's specifications prior to installing on a machine.
Refer to Operation and Safety or Service and Maintenance
Manuals. Purchase individual tire and/or rim only if able to
foam fill tire and wheel assembly, otherwise, purchase
complete assembly.
201
Ref
Right Side Tire and Wheel Assembly Options (See Items 301-
302 for Breakdown):
201
0272055
2
Foam-Filled Tire and Wheel Assembly
201
1001112716
2
Solid Tire and Wheel Assembly
202
Ref
Left Side Tire and Wheel Assembly Options (See Items 301-302
for Breakdown):
202
0272056
2
Foam-Filled Tire and Wheel Assembly
202
1001112669
2
Solid Tire and Wheel Assembly
203
0701619
64
Bolt M16 x 55mm (16 Per Wheel)
204
4892000
64
Flatwasher 5/8in Hardened (16 Per Wheel)
Ref
TIRE AND WHEEL ASSEMBLY COMPONENTS
301
Ref
Tire Only Options:
301
4520261
4
Tire 445/50D710 (For Foam Filling)
301
Not Available
Tire 445/65-24 (Solid) (Purchase Items 201 or 202)
302
Ref
Rim Only Options:
302
4860236
4
Rim, Wheel (Foam-Filled Tires)
302
Not Available
Rim (Solid Tires) (Purchase Items 201 or 202)
