Page 43
SECTION 2 - TURNTABLE
3121263
1500SJ
43
FIGURE 2-3. TURNTABLE SWING DRIVE AND BEARING INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0271596
Ref
SWING DRIVE INSTALLATION
D
1
0100019
AR
Compound, Locking
2
0682418
5
Bolt 7/8- 9NC x 2-1/4 (Grade 8)
3
Ref
Swing Motor/Hub Assembly (See SWING MOTOR/HUB
ASSEMBLY for Breakdown)
3
1001134098
1
Swing Motor/Hub Assembly (was p/n 3160302) (Prior to SN
0300152139)
3
1001134098
1
Swing Motor/Hub Assembly (SN 0300152139 to Present)
4
3312002
1
Nut, Jam 5/8-11NC
5
3900223
1
Screw, Shoulder
6
3952020
1
Setscrew 5/8-11NC x 2-1/2
7
4071041
1
Shim
8
4892400
5
Flatwasher 7/8in Hardened
0271512
Ref
TURNTABLE BEARING AND LUBE INSTALLATION
B
101
0100019
AR
Compound, Locking
102
0440251
1
Bearing, Turntable
103
0682026
40
Bolt 5/8-11NC x 3-1/4 (Grade 8)
104
0682040
40
Bolt 5/8-11NC x 5 (Grade 8)
105
2180002
2
Fitting, Grease
106
2180344
2
Fitting, Bulkhead
107
2220063
2
Fitting, Adapter
109
2750528
2
Hose
110
4892000
80
Flatwasher 5/8, Hardened
151
2915072
1
Kit Bearing (Includes Items 102, 103, 104 & 110)
1001110186
Ref
TURNTABLE LOCK INSTALLATION
C
201
0641524
1
Bolt 5/16-18NC x 3
202
1260017
9 in/23cm
Chain - #3
203
3311505
1
Locknut 5/16-18NC
204
3421563
1
Pin, Turntable Lock
205
3421565
1
Pin, Snap
206
3760170
2
Ring, Quick Release
