SECTION 2 - TURNTABLE
3121263 1500SJ 143
FIGURE 2-24. 7500W SKYPOWER GENERATOR INSTALLATION - DEUTZ MACHINES (Prior to SN
0300182753)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref 7500W SKYPOWER GENERATOR INSTALLATION (Prior to SN
0300182753)
1001125427 Ref 60Hz Spec (Deutz TD2011 Engines) B
1001137590 Ref 60Hz Spec (Deutz TCD2.9L4 Engines) D
1001125428 Ref 50Hz Spec (Deutz TD2011 Engines) A
1001137591 Ref 50Hz Spec (Deutz TCD2.9L4 Engines) A
Ref Note: SkyPower Generator is Standard On ANSI and CSA
Specs. Optional on All Other Specs.
Ref Note: See ELECTRICAL SECTION for Boom Cable Installation.
1 0100011 AR Compound, Locking
2 0100019 AR Compound, Locking
3 0100048 AR Grease, Dielectric
4 Ref Belt, Generator Options:
4 0480128 1 60Hz Spec (Deutz TD2011 Engines)
4 1001142645 1 60Hz Spec (Deutz TCD2.9L4 Engines)
4 0480129 1 50Hz Spec (Deutz TD2011 Engines)
4 1001136357 1 50Hz Spec (Deutz TCD2.9L4 Engines)
5 0641404 5 Bolt 1/4-20NC x 1/2
6 0641508 4 Bolt 5/16-18NC x 1
7 0641516 3 Bolt, 5/16-18NC x 2
8 0641810 4 Bolt, 1/2-13NC x 1-1/4
8 4300157 AR Stud 1/2in-13NC (Not Shown)
9 Ref Box, Switch-Weatherhead Options:
9 0860038 2 60Hz Spec
9 Not Available 1 50Hz Spec (Supply Locally)
10 Ref Box, Generator Control Options:
10 0861538 1 60Hz Spec
10 0861572 1 50Hz Spec
10 7024488 1 Card, Circuit - Generator Power
10 Not Available 1 Fuse (Purchase Locally)
10 7024489 1 Card, Circuit - Control
Ref Note: Same Circuit Card (P/N 7024489) is used for both
60Hz & 50Hz. When replacing card, rocker switch on card
must be set for required application.
10 70000619 1 Harness, Circuit Card
11 Ref Junction Box Assembly Options (See Items 101-128 for
Breakdown):
11 0861542 1 60Hz Spec (Deutz TD2011 Engines)
11 1001142914 1 60Hz Spec (Deutz TCD2.9L4 Engines)
11 0861567 1 50Hz Spec
12 0902888 1 Bracket, Generator Junction Box
13 0962520 1 Bushing, Taper
14 Ref Generator, 7500W Options:
14 2460048 1 Deutz TD2011 Engines
14 1001136988 1 Deutz TCD2.9L4 Engines
14 70001100 1 Rotor/Armature (Not Shown - Includes p/n 70000863 &
70001384)
14 70001384 1 Bearing, Ball Radial (Not Shown)
14 70000863 1 Fan (Not Shown)
14 Ref Stator Options (Not Shown):
