SECTION 3 - BOOM
3121263
1500SJ
183
FIGURE 3-7. PLATFORM SUPPORT AND VALVES (BOOM MOUNTED) INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
PLATFORM SUPPORT INSTALLATION
0272070
Ref
Machines without Load Sensing and without SkyGlazier
F
See Note
Ref
Machines without Load Sensing and with SkyGlazier (Note:
For Replacement Parts, Contact JLG Customer Service and
Request Manual p/n 3124242.)
See Note
Ref
Machines with Load Sensing and without SkyGlazier (Note:
For Replacement Parts, Contact JLG Customer Service and
Request Manual p/n 3124287.)
See Note
Ref
Machines with Load Sensing and with SkyGlazier (Note: For
Replacement Parts, Contact JLG Customer Service and
Request Manual p/n 3124287.)
1
0100011
AR
Compound, Locking
2
0641812
8
Bolt 1/2-13NC x 1-1/2
3
0642684
1
Bolt 1-8NC x 10-1/4
4
0681608
8
Bolt 3/8-16NC x 1 (Grade 8)
5
3300243
1
Locknut 1-8NC
6
3311805
8
Locknut 1/2-13NC
7
4846573
1
Support Weldment
8
4891600
8
Flatwasher 3/8 Hardened
9
4891800
8
Flatwasher 1/2 Hardened
10
4892600
1
Flatwasher 1 Hardened
1001119717
Ref
VALVES INSTALLATION
F
101
0100011
AR
Compound, Locking
107
0641538
4
Bolt 5/16-18NC x 4-3/4
108
0641608
6
Bolt 3/8-16NC x 1
116
3311505
9
Locknut 5/16-18NC
119
3900210
3
Screw, Button Head 5/16-18NC x 3/4
120
3900283
3
Screw, Button Head 3/8-16NC x 3/4
127
4711500
11
Flatwasher 5/16 Thin
128
4711600
8
Flatwasher 3/8 Thin
132
1001118286
1
Jib Valve Assembly (See JIB VALVE ASSEMBLY for Breakdown)
134
1001119702
1
Platform Valve Assembly (See PLATFORM VALVE ASSEMBLY
for Breakdown)
135
1001119703
1
Plate, Valve Mounting
136
1001119704
1
Plate, Valve Protection
137
1001119706
1
Plate, Valve Mounting
138
88662523
4
Nut, Retainer
139
1001119212
1
Enclosure Box Assembly (See ENCLOSURE BOX ASSEMBLY for
Breakdown)
140
0641508
1
Bolt 5/16-18NC x 1
141
4751500
1
Flatwasher 5/16 Regular
142
8406105
2
Clamp
