SECTION 3 - BOOM
3121263 1500SJ 171
FIGURE 3-4. ACTUATOR ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
Ref ACTUATOR ASSEMBLY
1001118865 Ref Platform Rotate Actuator Assembly C
1001119901 Ref Jib Rotate Actuator Assembly D
1 Not Available 1 Case/Bracket Weldment
2 Ref Shaft Options:
2 7017162 1 Platform Rotate Actuator
2 70002853 1 Jib Rotate Actuator
3 Ref Sleeve, Piston Options:
3 7017163 1 Platform Rotate Actuator
3 70002854 1 Jib Rotate Actuator
4 Ref Cap, End Options:
4 7017164 1 Platform Rotate Actuator
4 70002855 1 Jib Rotate Actuator
5 Not Available 3 Capscrew 1/4-20 (Grade 8)
20 See Note 1 Seal, Rod (Note: Use Item 52)
22 See Note 1 Seal, Piston (Note: Use Item 52)
24 See Note 1 Seal, Cap (Note: Use Item 52)
25 See Note 2 Packing, Bearing (Note: Use Item 52)
27 See Note 1 Ring, Cap Back-Up (Note: Use Item 52)
31 See Note 2 Seal (Note: Use Item 52)
32 See Note 2 Bearing, Shaft (Note: Use Item 51)
34 See Note 2 Thrustwasher (Note: Use Item 51)
41 Ref Motion Control Valve Assembly
41 7017183 1 Valve Assembly for Platform Rotate Actuator
41 7017193 2 Replacement Cartridge (Located on Top and Bottom of Valve)
(Valve for Platform Rotate Actuator Only)
41 Not Available 2 Seal Kit - 7017193 Cartridge
41 Not Available 1 Replacement Cartridge (Not Shown - Located on Side of
Valve) (Valve for Platform Rotate Actuator Only)
41 Not Available 1 Seal Kit - 7017193 Cartridge
41 70002859 1 Valve Assembly for Jib Rotator Actuator (No Service Parts
Available)
42 Ref Bushing, Shaft Options:
42 7017195 2 Platform Rotate Actuator
42 Not Available 1 Jib Rotate Actuator
51 Ref Bearing Kit Options (Includes Items 32 & 34):
51 7017159 1 Platform Rotate Actuator
51 70002857 1 Jib Rotate Actuator
52 Ref Seal Kit Options (Includes Items 20, 22, 24, 25, 27 & 31):
52 Ref Kit for Platform Rotate Actuator
52 70005856 1 Standard
52 70000342 1 Cold Climate
52 Ref Kit for Jib Rotate Actuator
52 70002856 1 Standard
52 Not Available 1 Cold Climate
53 Ref Hardware Kit
53 7017142 1 Platform Rotate Actuator
53 70002858 1 Jib Rotate Actuator
54 70001697 4 Screw, Countersunk 1/4-20NC x 3/8 (Grade 8)
