Page 233

SECTION 5 - CYLINDER
3121263
1500SJ
233
FIGURE 5-6. LIFT (JIB) CYLINDER ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
JIB LIFT CYLINDER ASSEMBLIES
1001118082
Ref
Without Cold Weather Plus Package (Prior to SN 0300185792)
C
1001140104
Ref
Without Cold Weather Plus Package (SN 0300185792 to
Present)
C
1001140104
Ref
With Cold Weather Plus Package
C
1
0100011
AR
Compound, Locking
2
0630535
3
Capscrew 1/4-20NC x 1-1/8
3
0791003
1
Screw #10-24NC x 3/8
4
0961897
1
Bushing, Tapered
5
1320136
1
Clamp, Cable
6
1683063
1
Head
7
2220883
1
Plug, O-Ring
8
2220885
2
Plug, O-Ring
9
2220886
1
Plug, O-Ring
10
3020039
AR
Lubricant
11
3480282
1
Piston
12
3760371
1
Ring, Washer
13
3931420
8
Capscrew 1/4-20NC x 1-1/4
14
3931824
8
Capscrew 1/2-13NC x 1-1/2
15
3951003
1
Setscrew #10 x 3/8
16
4100099
1
Spacer
17
4640999
1
Cartridge, Holding Valve (Non Vented)
17
2900792
1
Seal Kit - 4640999 Cartridge Valve
18
4641248
1
Cartridge, Counterbalance Valve (Non Vented)
18
See Note
1
Seal Kit - 4641248 Cartridge Valve (Note: Not Available for
Purchase)
19
1001117991
1
Sensor, Cylinder Length
20
1001118070
1
Cap, Retainer
21
1001118084
1
Barrel Weldment
21A
0961950
2
Bushing
22
1001118086
1
Rod Weldment
22A
0961950
2
Bushing
100
Ref
Seal Kit Options (Includes Items 101-109):
100
1001118973
1
Without Cold Weather Plus Package (Prior to SN 0300185792)
100
1001139996
1
Without Cold Weather Plus Package (SN 0300185792 to
Present)
100
1001139996
1
With Cold Weather Plus Package
101
See Note
2
Ring, Wear (Note: Use Item 100)
102
See Note
1
Ring, Back-up (Note: Use Item 100)
103
See Note
2
Ring, Lock (Note: Use Item 100)
104
See Note
2
Ring, Back-up (Note: Use Item 100)
105
See Note
2
O-Ring (Note: Use Item 100)
106
See Note
1
O-Ring (Note: Use Item 100)
107
See Note
1
Seal (Note: Use Item 100)
108
See Note
1
Wiper, Rod (Note: Use Item 100)
109
See Note
2
Seal (Note: Use Item 100)
200
1001119105
1
Sensor Magnet Kit (Includes Items 201-203)
201
1001117994
2
Sleeve, Spacer
202
1001118066
1
Magnet, Sensor
203
1001118069
1
Ring, Internal Retaining
