JLG 1500SJ Parts Manual User Manual
Page 181
SECTION 3 - BOOM
3121263
1500SJ
181
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
44
1001133329
NLA
Sensor, Angle Indicator (Use p/n 1001147479) (SN 0300157203
through 0300184724)
44
1001147479
4
Sensor, Angle Indicator (SN 0300184724 to Present)
45
4360578
1
Switch, Limit (Boom Length) (Note: Control System must be
recalibrated when Switch is replaced)
46
4460914
2
Terminal, Base
47
4460968
1
Connector, Strain Relief
48
4711400
13
Flatwasher 1/4 Thin
49
4711500
2
Flatwasher 5/16 Thin
50
4711600
7
Flatwasher 3/8 Thin
51
4750800
6
Flatwasher 1/4 Regular
52
4846484
1
Mount, Switch
53
4891400
4
Flatwasher 1/4 Hardened
54
8310070
6
Pushnut 3/8
55
1001118373
1
Bracket, Sensor Mounting
56
1001118930
1
Cover, Sensor
57
1001118931
2
Mount, Sensor
58
1001118971
2
Sensor, Angle Indicator (Main Boom Protractor) (Note: Control
System must be recalibrated when Sensor is replaced)
59
1001119033
2
Link, Sensor
60
1001119137
1
Sleeve, Spacer
61
1001119141
1
Sleeve, Spacer
62
Ref
Sensor, Angle Indicator (Jib Rotate) Options (Note: Control
System must be recalibrated when Sensor is replaced):
62
1001119223
1
Sensor, Angle Indicator (Prior to SN 0300152974)
62
1001135479
1
Sensor, Angle Indicator (SN 0300152974 to Present)
63
1001119729
1
Cover, Sensor
64
1001120028
1
Mount, Sensor
65
1001120048
1
Cover, Sensor
66
1001120049
1
Cover, Sensor
67
Ref
Pin, Angle Sensor Options:
67
1001135483
1
Pin, Angle Sensor (was p/n 1001120057) (Prior to SN
0300152974)
67
1001135483
1
Pin, Angle Sensor (SN 0300152974 to Present)
68
1001120076
1
Mount, Sensor
69
Ref
Adapter Options:
69
1001135484
1
Adapter (was p/n 1001120081) (Prior to SN 0300152974)
69
1001135484
1
Adapter (SN 0300152974 to Present)
70
1001120084
1
Bracket
71
1001120104
2
Switch, Proximity (Jib Telescope) (Note: Control System must be
recalibrated when Switch is replaced)
72
88662530
2
Nut, Retainer
73
0641412
1
Bolt 1/4-20NC x 1 1/2
74
0641504
1
Bolt 5/16-18NC x 1/2
75
1320061
2
Clamp, Cable
76
1001130781
1
Conduit (Prior to SN 0300152974)
77
3311505
2
Locknut 5/16-18NC
