SECTION 7 - ELECTRICAL
3121263
1500SJ
303
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
812G
0903484
1
Bracket, AC Receptacle
813
1001112987
1
ClearSky Telematics Components (Standard on Machines
delivered in North America. Optional on all other machines.)
B
813A
4460496
1
Lockwasher, Terminal
813A
4460497
1
Nut, Terminal
813B
1001103356
1
Ground Cable
814
1001111914
1
ClearSky Telematics Harness (Standard on Machines delivered in
North America. Optional on all other machines.)
B
814A
1001116994
1
Plug, Male - 23 Position
814A
4460871
AR
Socket
814A
4460905
AR
Plug, Seal
814B
4460539
2
Plug, Male - 3 Position (Includes Wedge Lock and Seal)
814B
4460944
6
Socket
814B
77363244
2
Wedge Lock
814C
4460945
2
Bulkhead, 3 Way Female
814C
1001129408
1
Plug, Male - 3 Position with 120 ohm Resistor (Includes Wedge
Lock)
814D
1001112612
2
Connector, Diagnostic
814D
4460943
AR
Pin
814D
4460464
AR
Pin
814D
4460466
AR
Plug, Seal
814D
1001106736
2
Cap, Dust
815
70002296
1
Harness, Telematics Antenna (Includes Antenna) (Note: No other
parts available)
816
1001149818
1
Strobe Light Harness
B
816A
4460320
1
Connector, Female - 2 Position
816A
4460267
2
Pin, Male
816B
4460897
1
Connector, Female - 2 Position
816B
4460464
2
Pin, Male
Ref
TOOLS (NOT SHOWN)
7002821
1
Crimper (For Wire to Pin/Socket Connections)
7002823
1
Extractor (For Removal of Pin/Socket from Connectors)
4460467
1
Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors)
4460510
1
Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors)
7002828
1
Stripper, Wire
1001137005
1
Cable Kit, Software
