SECTION 3 - BOOM
3121263
1500SJ
185
FIGURE 3-8. PLATFORM VALVE ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001119702
Ref
PLATFORM VALVE ASSEMBLY
E
Ref
Cartridges:
1
Not Available
1
Block, Valve
2
70003025
1
Valve, Cartridge (Valve Inlet)
2
70004050
1
Seal Kit - 70003025 Cartridge
2
70004051
1
Nut, Coil
2
70003026
1
Coil
3
70003021
1
Valve, Cartridge (Valve Inlet)
3
70004052
1
Seal Kit - 70003021 Cartridge
4
7024899
1
Valve, Cartridge (Platform Level)
4
7017402
1
Seal Kit - 7024899 Cartridge
4
7022390
1
Nut, Coil
4
70003023
1
Spacer, Coil
4
7024885
2
Coil
5
70003019
1
Valve, Cartridge (Platform Level)
5
70004052
1
Seal Kit - 70003019 Cartridge
6
70003019
1
Valve, Cartridge (Platform Level)
6
70004052
1
Seal Kit - 70003019 Cartridge
7
70003027
1
Valve, Cartridge (Platform Rotate)
7
70004052
1
Seal Kit - 70003027 Cartridge
8
7024899
1
Valve, Cartridge (Platform Rotate)
8
7017402
1
Seal Kit - 7024899 Cartridge
8
7022390
1
Nut, Coil
8
70003023
1
Spacer, Coil
8
7024885
2
Coil
10
70003028
1
Valve, Cartridge (Jib Lock Pin)
10
70004053
1
Seal Kit - 70003028 Cartridge
10
70004054
1
Nut, Coil
10
70003026
2
Coil
11
70003019
1
Valve, Cartridge (Jib Lock Pin)
11
70004052
1
Seal Kit - 70003019 Cartridge
13
2221086
4
Check, Pressure
Ref
Fittings:
101
2110404
6
Fitting, Straight
102
2110606
1
Fitting, Straight
103
2110808
1
Fitting, Straight
107
2110406
1
Fitting, Straight
