SECTION 2 - TURNTABLE
82 1500SJ 3121263
ITEM PART NUMBER QTY DESCRIPTION REV
305D 70020336 1 Gasket
305E Not Available 1 Cover W/Filter (Purchase p/n 70003165)
305F Not Available 1 Spring, Draw (Purchase p/n 70003165)
305G 70020336 1 Gasket
305H 70020336 4 Capscrew M6 x 65-8.8
305J 70020336 1 Capscrew M6 x 45-8.8
305K Not Available 8 Capscrew M5 x 10-8.8
305L 70020336 1 O-Ring
305M Not Available 2 O-Ring
305N Not Available 2 Cup, Spring
305P 70020336 2 Pin, Cylinder
305Q Not Available 2 Nut, Coil
310 Not Available 1 Housing
313 Not Available 2 Pin, Dowel
314 Not Available 1 Pin, Cylinder
320 70003166 1 Screw 7/8-14NF (Front Drive Pump Only)
321 70003166 1 Screw 9/16-18NF
322 70003166 1 Screw 7/16-20NF
324 70003166 1 Screw M10 x 1
327 70003166 1 Pin, Double Break-Off
328 70003166 2 Orifice
331 70003166 2 Pin, Clamping
341 70003166 1 O-Ring
Ref Seal Kit Options:
401 70003167 1 Seal Kit - Drive Shaft (Includes Items 301L & 301M)
402 70003168 1 Seal Kit - Control Group - Hydraulic (Includes Items 302B, 302D
& 302E)
403 70003169 1 Seal Kit - Port Plate Group (Includes Items 303F-303K)
404 70020336 1 Seal Kit - Control Module (Includes Items 305D, 305G-305J,
305L & 305P)
405 70003166 1 Seal Kit - Front Pump (Includes Items 320-322, 324, 327, 328,
331 & 341)
