SECTION 2 - TURNTABLE
3121263
1500SJ
105
FIGURE 2-14. ROTARY COUPLING AND COLLECTOR RING INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001119273
Ref
ROTARY COUPLING AND COLLECTOR RING INSTALLATION
A
1
0100011
AR
Compound, Locking
2
0641812
3
Bolt 1/2-13NC x 1-1/2
3
0641820
2
Bolt 1/2-13NC x 2-1/2
4
0902790
1
Bracket, Swivel
5
1001119040
1
Rotary Coupling and Collector Ring Assembly (See Items 101- 112
for Breakdown)
6
3311805
2
Locknut 1/2-13NC
8
4751800
7
Flatwasher 1/2 Regular
9
3322201
2
Nut 3/4-16NC
1001119040
Ref
ROTARY COUPLING AND COLLECTOR RING ASSEMBLY
C
101
70001102
1
Coupling, Rotary
101
Not Available
Bearing
101
70001101
1
Seal Kit - Coupling
102
70003485
1
Contactor, Rotary Circuit (Does not include connector or pins)
(was p/n 7026029)
103
0641506
4
Bolt 5/16-18NC x 3/4
104
3931512
2
Capscrew 5/16-18NC x 3/4
105
70003484
1
Arm, Torque (was p/n 70000780)
106
80334251
1
Adapter
107
7026030
1
Plate, Cam
108
7026031
1
Sensor, Proximity
109
3931008
2
Capscrew #10-32 x 1/2
110
7026032
1
Pin, Dowel
111
0100048
AR
Grease, Silicone (Apply to Contactor Connector)
112
1001133759
1
Sensor, Angle
