SECTION 1 - FRAME
10 1500SJ 3121263
ITEM PART NUMBER QTY DESCRIPTION REV
49 4750800 8 Flatwasher #8 Regular
50 4846637 4 Extension, Axle
51 4846383 1 Box, Axle Pivot
52 0681813 12 Bolt 1/2-13NC x 1-5/8 (Grade 8)
53 0681814 18 Bolt 1/2-13NC x 1-3/4 (Grade 8)
54 0681815 12 Bolt 1/2-13NC x 1-7/8 (Grade 8)
55 0681816 6 Bolt 1/2-13NC x 2 (Grade 8)
56 4711800 48 Flatwasher 1/2 Thin
57 4460968 4 Connector, Strain Relief (Not Shown)
Ref AXLE INSTALLATION - OPTIONAL PARTS
0271934 Ref Fixed Axle J
105 0363076 2 Bar, Stop
115 0641814 4 Bolt 1/2-13NC x 1-3/4
144 4071049 6 Shim 11 Gauge
145 4071050 4 Shim 16 Gauge
0271521 Ref Oscillating Axle J
212 0642020 4 Bolt 5/8-11NC x 2-1/2
217 1684081 2 Oscillating Axle Cylinder Assembly (See CYLINDER SECTION
for Breakdown)
220 3312005 4 Locknut 5/8-11NC
225 3422833 2 Pin
226 3422915 2 Pin
231 3841258 4 Keeper, Pin
246 4712000 4 Flatwasher 5/8 Thin
254 3520054 4 Plug
