SECTION 4 - PLATFORM
3121263 1500SJ 201
FIGURE 4-2. PLATFORM COMPONENTS INSTALLATION (FALL ARREST PLATFORM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref PLATFORM ASSEMBLY (FALL ARREST) (OPTIONAL)
3510868 Ref ANSI Spec (Prior to SN 0300186185) F
1001144596 Ref ANSI Spec (SN 0300186185 to Present) D
3510877 Ref Australian and CE Specs (Prior to SN 0300186983) D
1001175535 Ref Australian and CE Specs (SN 0300186983 to Present) A
Ref Note: Replacement Decals Must be Ordered Separately - See
DECALS SECTION.
1 0681814 2 Bolt 1/2-13NC x 1-3/4
2 0681822 6 Bolt 1/2-13NC x 2-3/4
3 0962270 2 Bearing, Oilite
4 1702773 1 Decal - JLG
5 Ref Decal - Safety Options:
5 1705014 1 ANSI Spec
5 1706501 1 Australian and CE Specs
6 2410014 1 Gate Weldment
7 3271805 8 Locknut 1/2-13NC
8 3311605 1 Locknut 3/8-16NC
9 Not Available 1 Platform Weldment (Purchase Platform Assembly)
10 3520072 1 Cap-Plug
11 3890040 1 Cable, Fall Arrest
12 3900054 1 Bolt 1/2-13NC x 1-3/4
13 4711800 2 Flatwasher 1/2 Thin
14 4751800 6 Flatwasher 1/2 Regular
15 Ref Decal - Drop Bar Options:
15 1706385 1 ANSI Spec
15 1706493 1 Australian and CE Specs
