3120741 9-1
S
E
C
T
I
O
N
9
R
E
C
O
M
M
E
N
D
E
D
S
E
R
V
I
C
E
P
A
R
T
S
S
T
O
C
K
SECTION 9 RECOMMENDED SERVICE PARTS STOCK
MODELS 800A/800AJ
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10 10-20 20 OR MORE
STANDARD PARTS Ref Ref Ref
2120168 Element, Filter (Figure 2-1) 4 8 12
2120150 Element Filter (Figure 2-1) 4 8 12
7012944 Coil (Figure 2-1 & 2-2) 1 1 1
7018991 Coil (Figure 2-2) 1 1 1
7012772 Coil (Figure 2-2 & 2-3) 1 1 1
7012943 Coil (Figure 2-2) 1 1 1
7012664 Element, Air Cleaner (Figures 2-10, 2-13 & 2-17) 1 Dozen 1 Dozen 1 Dozen
3740067 Relay (Figures 2-10, 2-13 & 2-17) 1 1 1
4360294 Breaker, Circuit (Figures 2-10, 2-11, 2-13, 2-16 & 2-17) 1 1 1
7014817 Breather, Hydraulic Tank (Figure 2-19) 1 2 3
4360475 Switch, Mushroom (Figures 2-22 & 4-5) 1 1 1
4360469 Switch, Key (Figure 2-22) 1 1 1
2860030 Key, Replacement (Figure 2-22) 1 1 1
4360476 Contact, Switch Block (Figures 2-22 & 4-5) 1 1 1
3740049 Relay (Figure 2-22) 1 1 1
2940074 Latch (Figure 4-1 & 4-2) 1 1 1
1001129555 Controller (Lift and Swing) (Figure 4-5 & 4-7) 1 1 1
1001118416 Controller (Drive and Steer) (Figure 4-5 & 4-9) 1 1 1
4360387 Switch, Push Button (Figure 4-5 & 4-10) 1 1 1
4360407 Controller, Speed (Figure 4-5) 1 1 1
4360331 Switch, Toggle (Figure 4-2 & 4-5) 1 1 1
4360232 Breaker, Circuit (Figure 4-5) 1 1 1
3990010 Diode (Figure 7-4) 2 2 2
VARIABLE PARTS Ref Ref Ref
7016331 Filter, Oil (Deutz Engine Machines) (Figure 2-10) 1 Dozen 1 Dozen 1 Dozen
7016328 Filter, Fuel (Deutz Engine Machines) (Figure 2-10) 1 Dozen 1 Dozen 1 Dozen
1660234 Coupling, Pump (Deutz Engine Machines) (Figure 2-10) 1 1 1
7021868 Filter, Oil (Ford Engine Machines) (Figure 2-13) 1 Dozen 1 Dozen 1 Dozen
1660250 Coupling, Pump (Ford Engine Machines) (Figure 2-13) 1 1 1
1600314 Controller, ECM (Ford Engine Machines) (Figure 2-13) 1 1 1
91083218 Filter, Fuel (Ford Engine Machines) (Figure 2-13) 1 Dozen 1 Dozen 1 Dozen
7023634 Filter, Oil (Isuzu Engine Machines) (Figure 2-17) 1 Dozen 1 Dozen 1 Dozen
7023641 Filter, Fuel (Isuzu Engine Machines) (Figure 2-17) 1 Dozen 1 Dozen 1 Dozen
1660239 Coupling, Pump (Isuzu Engine Machines) (Figure 2-17) 1 1 1
3740080 Relay (Machines with Generator Option) (Figures 2-11, 2-
13 & 2-16) 1 1 1
4360336 Switch, Toggle (Machines with Generator Option) (Figures
2-11 & 2-16) 1 1 1
