FIGURE 5-11. TELESCOPE CYLINDER ASSEMBLY - TOWER
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1683606 TELESCOPE CYLINDER ASSEMBLY Ref J
1 1683632 Barrel Weldment 1
2 1683629 Rod Weldment 1
3 3480211 Piston 1
4 0961897 Bushing, Tapered 1
5 0630535 Bolt 1/4in-20NC x 1-1/8in 3
6 4567413 Spacer, Tube 1
7 3931508 Bolt, Socket Head 5/16in-18NC x 1/2in 1
8 Not Used
9 Use 2901273 Wiper 1
10 Use 2901273 Seal 1
11 Use 2901273 O-Ring 1
12 Use 2901273 Ring, Back-up 1
13 Use 2901273 Ring, Wear 2
14 Use 2901273 O-Ring 1
15 Use 2901273 Ring, Back-up 2
16 Use 2901273 Seal 2
17 Use 2901273 Ring, Lock 2
18 2220886 Plug, O-Ring 1
19 2220885 Plug, O-Ring 2
20 1683061 Head 1
21 3760370 Ring, Washer 1
22 3340834 Pad, Support 1
23 3340833 Pad, Support 1
24 4711600 Flatwasher 3/8in Narrow 10
25 0641552 Bolt 5/16in-18NC x 6-1/2in 3
26 3271605 Locknut 3/8in-16NC 2
27 3931720 Capscrew 7/16in-14NC x 1-1/4in 2
28 0100038 Primer, Locking AR
29 0100011 Compound, Locking AR
30 2220883 Plug, O-Ring 1
31 0100063 Loctite #RC609 AR
32 4641032 Valve Assembly (No serviceable parts - sold as assembly
only) 1
32A 7024397 O-Ring 2
33 Hardware Options: 4
0641420 Bolt 1/4in-20NC x 2-1/2in (Prior to SN 0300056439)
3931448 Bolt (SN 0300056439 to SN 0300069000)
34 1320011 Clamp (SN 0300056439 to SN 0300069000) 1
35 3572604 Plate, Proximity Switch Target (SN 0300056439 to
SN 0300069000) 1
36 3572605 Plate, Proximity Switch Mount (SN 0300056439 to
SN 0300069000) 1
37 to 39 Not Used
40 2901273 Seal Kit (Includes Items 9-17) 1
