JLG 800A_AJ ANSI Parts Manual User Manual
Page 269
3120741
7-21
SECTION 7
ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
202C
4460509
Socket, Female
8
202D
4460473
Clamp. Cable
2
202E
4460466
Seal, Plug
8
203
4922579
Harness Assembly - Tower Boom (18/2)
1
1060902
Cable, Electrical - 18/2
47ft/14.3m
203A
4460465
Socket, Female
2
4460891
Connector, Terminal - 2 Position
1
204
4922580
Harness Assembly - Main Boom (18/2)
1
1060902
Cable, Electrical - 18/2
27ft/8.2m
204A
4460464
Pin, Male
2
4460897
Plug, Terminal - 2 Position
1
205
4922577
Harness Assembly - Tower Boom (18/2)
1
206
4922578
Harness Assembly - Main Boom (18/2)
1
207
4922215
Harness Assembly - Main Boom (10/3)
1
208
4922217
Harness Assembly - Tower Boom (10/3)
1
209
1320256
Clamp, Block (Not Shown-Located on back of T/T)
1
210
4922581
Harness Assembly (18/2)
1
211
1001094470
Harness, Boom Cable Jumper
1
211A
1060896
Cable, Electrical - 4 #12 AWG, 8 #18 AWG & 1 STP
#18 AWG
1ft/0.3m
211B
4460465
Socket, Female
11
211C
4460865
Connector - 19 Position
1
211D
4460509
Socket, Female
4
211E
4460473
Clamp. Cable
1
211F
4460466
Seal, Plug
8
211G
4460464
Pin, Male (16 Gauge)
8
211H
4460866
Connector - 19 Position
1
211J
4460508
Pin, Male (12 Gauge)
4
211K
4923613
Harness, Tilt Switch
1
211L
1060978
Cable, Electrical - 18/3
2ft/0.6m
211M
1001097051
Connector - 4 Position
1
211N
1001097082
Pin, Male (Gold)
3
211P
4460464
Pin, Male (16 Gauge)
3
211Q
4460466
Seal, Plug
1
211R
1001094400
Tilt Sensor Harness (Boom) (Includes Sensor)
1
C
211S
4461077
Terminal, Plug - 4 Position
1
See Note
Socket, Female (Note: Not Available for
Purchase.)
3
4933195
GROUND CONTROL BOX DIAGRAM (DEUTZ
ENGINE)
Ref
3/C
301
2920129
Bulb, Light
6
302 to 305
Not Used
306
4460871
Socket, Female
6
307
2400065
Fuse, 30Amp (Not Shown)
1
308
2400066
Fuse, Holder W/Cover (Not Shown)
1
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064009
ONLY)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
