3120741 1-11
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
Note: Assemblies may require ballast/foam filling to
manufacturer’s specifications prior to installing on a
machine. Refer to Operation & Safety or Service &
Maintenance Manuals. Purchase individual tire and/or
rim only if able to foam fill tire & wheel assembly, oth-
erwise, purchase complete assembly, Ref
201 Decal Options: 1
1702701 95 PSI IN385/65D19.5 (15 x 19.5 Tires)
1702739 85 PSI IN445/55D19.5 (18 x 19.5 Tires)
202 Tire Options: 1
4520204 IN385/65D19.5 (15 x 19.5)
4520252 15-625
4520205 IN445/55D19.5 (18 x 19.5)
4520253 18.625
203 4640113 Valve, Air 1
204 Rim, Wheel Options: 1
4860148 11.75 x 19.5
4860224 13 x 24.5
4860188 14 x 19.5
4860225 15 x 24.5
205 1120552 Cap Valve Stem (Green) (W/Sealant Only) 1
206 1300019 Chemical, Tire Sealant (Green) (W/Sealant Only) AR
207 1705364 Decal - Tire Sealant (W/Sealant Only) 1
0256196 WHEEL COVER INSTALLATION (OPTIONAL) Ref 2/A
301 1670776 Cover, Wheel 4
302 0641550 Bolt 5/16in - 18NC x 6-1/4in 20
303 0100011 Compound, Locking AR
FIGURE 1-2. TIRE AND WHEEL DRIVE INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
