JLG 800A_AJ ANSI Parts Manual User Manual
Page 13
3120741
1-5
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
223
3422753
Kingpin
4
224
3422754
Pin, Attach
2
HUB INSTALLATION (2WD ONLY) OPTIONS:
Ref
0258288
Prior to SN 0300056875
Ref
C
0270209
SN 0300056875 to SN 0300069000
Ref
B
301 to 302
Not Used
303
0682016
Bolt 5/8in-16NC x 2in (Grade 8)
16
304 to 305
Not Used
306
2780229
Hub Assembly (See Items 401-412 for Breakdown)
2
307
Not Used
308
3300007
Lugnut
20
2780229
HUB ASSEMBLY (2WD ONLY)
Ref
A
401
7017052
Spindle (1 per Assembly)
2
402
7017053
Housing (1 per Assembly)
2
403
7010404
Cup, Bearing - Inner (1 per Assembly)
2
404
7010405
Cone, Bearing - Inner (1 per Assembly)
2
405
7017056
Cup, Bearing - Outer (1 per Assembly)
2
406
7017055
Cone, Bearing - Outer (1 per Assembly)
2
407
7010406
Seal, Lip (1 per Assembly)
2
408
7000265
Stud (10 per Assembly)
20
409
7017054
Dust Cap (1 per Assembly)
2
410
7017051
Washer, Special (1 per Assembly)
2
411
7017057
Washer, Tanged (1 per Assembly)
2
412
7017058
Nut, Bearing (1 per Assembly)
2
501
FRAME WELDMENT OPTIONS:
Ref
Frame Weldment - 2WD/2WS with Pneumatic Tires Options:
1
2360461
Prior to SN 0300068040
2360587
SN 0300068040 to SN 0300068374
2360600
SN 0300068374 to SN 0300069000
Frame Weldment - 2WD/2WS with Foam-Filled Tires Options:
1
2360488
Prior to SN 0300068040
2360588
SN 0300068040 to SN 0300068374
2360601
SN 0300068374 to SN 0300069000
Frame Weldment - 4WD/2WS with Pneumatic Tires Options:
1
2360489
Prior to SN 0300068040
2360589
SN 0300068040 to SN 0300068374
2360602
SN 0300068374 to SN 0300069000
Frame Weldment - 4WD/2WS with Foam-Filled Tires Options:
1
2360490
Prior to SN 0300068040
2360590
SN 0300068040 to SN 0300068374
2360603
SN 0300068374 to SN 0300069000
Frame Weldment - 4WD/4WS with Pneumatic Tires Options:
1
2360502
Prior to SN 0300068040
2360592
SN 0300068040 to SN 0300069000
FIGURE 1-1. AXLE AND STEERING INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
