3120741 5-11
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-5. LIFT CYLINDER ASSEMBLY - TOWER BOOM
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1683537 TOWER LIFT CYLINDER ASSEMBLY Ref G
1 Barrel Weldment Options: 1
Use 1683823 Prior to SN 0300045154 (was p/n 1683538)
1683823 SN 0300045154 to SN 0300069000
2 Head Options: 1
Use 1683818 Prior to SN 0300045154 (was p/n 1683073)
1683818 SN 0300045154 to SN 0300069000
3 3760374 Ring, Washer (Prior to SN 0300045154 Only) 1
4 1683539 Rod Weldment 1
5 3480236 Piston 1
6 2220883 Plug, O-Ring 2
7 2220888 Plug, O-Ring 1
8 4640509 Cartridge, Valve 1
2900792 Seal Kit - 4640999 Valve 1
9 4640605 Cartridge, Valve 1
2900792 Seal Kit - 4640605 Valve 1
10 0962102 Bushing, Garmax 4
11 Not Used
12 Use 2901537 O-Ring 1
13 Use 2901537 Ring, Lock 1
14 Use 2901537 Seal 2
15 Use 2901537 Ring, Lock 2
16 Use 2901537 O-Ring 1
17 Use 2901537 Ring, Back-up 2
18 Use 2901537 Ring, Wear 1
19 Use 2901537 Seal 1
20 Use 2901537 Wiper 1
21 0961903 Bushing, Tapered 1
22 3932240 Capscrew, Socket Head 3/4in x 2-1/2in 8
23 0100011 Compound, Locking AR
24 0100038 Primer, Locking AR
25 0100063 Loctite #RC609 AR
26 Hardware Options: 3
0641612 Bolt 3/8in-16NC x 1-1/2in (Prior to
SN 0300045154)
0630536 Bolt (SN 0300045154 to SN 0300069000)
27 to 29 Not Used
30 2901537 Seal Kit (Includes Items 12-20) 1
