3120741 8-3
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-1. DECALS INSTALLATION - STANDARD
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
STANDARD DECAL INSTALLATIONS Ref
0271038 JLG Logo Ref 1
0258513 800A Ref 8
0258514 800AJ Ref 8
0258706 MANUAL DESCENT DECALS INSTALLATION Ref 1
1 1703797 Decal - Danger/Warning 1
2 1703798 Decal - Danger/Warning 1
3 1703805 Decal - Danger/Electrocution 2
4 1703804 Decal - Warning/Crushing 4
5 Use 1707110 Decal - Legend (was p/n 1702784) 1
6 Use 1001095809 Decal - Legend (was p/n 1703808) 1
7 Decal - Model Options: 2
1703772 800A
1703773 800AJ
8 1702860 Decal - JLG Lift (5in) 2
9 1702774 Decal - JLG Lift (3-1/2in) 2
10 1702773 Decal - JLG (5in) 2
11 1702868 Decal - - No Hands 2
12 Decal - Attach Lanyard Here Options: 4
1702612 Prior to SN 0300061062
1704277 SN 0300061062 to SN 0300069000
13 Decal - 500LBS Max Capacity Options: 2
1704096 800A
1701645 800AJ
14 Decal - 500LBS Max Capacity Options: 1
1704104 800A
1702688 800AJ
15 3251813 Decal - USA 1
16 1701502 Decal - High Oil Level 1
17 1701503 Decal - Low Oil Level 1
18 1701504 Decal - Hydraulic Oil 1
19 1702153 Decal - Inspection 1
20 See Note Decal - Bar Code (Note: Not Available for
Purchase.) 1
21 1700584 Decal - Patent 1
22 See Note Nameplate - Serial Number (Note: Not Available for
Purchase.) 1
23 1701509 Decal - Manual 1
24 1702300 Decal - Tie Down /Lift 4
25 1701500 Decal - Tie Down /Lift 4
26 1701501 Decal - Arrow 4
27 Nameplate - 120V-60Hz 1
3251243 110V
3252507 220V
28 1703954 Decal - Manual Descent 1
29 1702901 Decal - Manual Descent Instructions Inside 1
30 1703959 Decal - Quik Stik 2
