7-20 3120741
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064009
ONLY)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
4922509 PLATFORM BOX HARNESS ASSEMBLY Ref 2/C
1 4922509 Harness, Console Box 1
2 to 18 Not Used
19 4460866 Connector - 19 Pin Receptacle 1
20 4460874 Connector - 35 Position (Natural) 1
21 4460875 Connector - 35 Position (Gray) 1
22 4460873 Connector - 35 Position (Black) 1
23 4460871 Socket, Female 48
24 4460464 Pin, Male (16 Gauge) 7
25 4460879 Terminal, Housing 2 Position 1
26 4460887 Terminal, (12 Gauge) 2
27 to 29 Not Used
30 4460418 Connector - 6 Position 4
31 4460419 Terminal, Female 12
32 4120035 Base, Light 7
33 to 35 Not Used
36 4460225 Connector - 6 Position 1
37 4460227 Pin 6
38 to 40 Not Used
41 4460508 Pin, Male (12 Gauge) 3
PLATFORM BOX ASSEMBLY COMPONENTS Ref
101 4460428 Connector, Strain Relief 2
102 4460470 Nut, Conduit 1
103 4460471 Washer 1
104 1060330 Cable, Electrical - 16/3 1
105 4460071 Connector, Strain Relief 1
0271374 BOOM CABLES INSTALLATION (800A) Ref B
201 4922575 Harness Assembly - Main Boom (12/4 -18/8) 1
1060896 Cable, Electrical - 4 #12 AWG, 8 #18 AWG & 1 STP
#18 AWG AR
201A 4460465 Socket, Female 11
201B 4460865 Connector - 19 Position 1
201C 4460509 Socket, Female 4
201D 4460473 Clamp. Cable 1
201E 4460466 Seal, Plug 8
201F 4460464 Pin, Male (16 Gauge) 11
201G 4460866 Connector - 19 Position 1
201H 4460508 Pin, Male (12 Gauge) 4
202 4922576 Harness Assembly - Tower Boom (12/4 - 18/8) 1
1060896 Cable, Electrical - 4 #12 AWG, 8 #18 AWG & 1 STP
#18 AWG 44ft/13.4m
202A 4460465 Socket, Female 22
202B 4460865 Connector - 19 Position 2
