3120741 5-21
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-9. STEER CYLINDER ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: Original Equipment Cylinder may have been
replaced with Service Replacement Cylinder. Iden-
tify p/n stamped on cylinder before ordering parts. Ref
STEER CYLINDER ASSEMBLIES Ref
1683605 2WS - Original Equipment Ref A
1683740 2WS - Service Replacement Ref B
1683740 4WS Ref B
1 7017210 Locknut 1
2 7017211 Piston 1
3 Use 7017215 Seal 1
4 Use 7017215 O-Ring 1
5 Barrel Weldment Options: 1
7017234 2WS (Prior to SN 0300042477)
7023023 2WS (SN 0300042477 to SN 0300069000)
7023023 4WS
6 7017236 Rod Weldment 1
7 7017213 Head 1
8 Use 7017215 O-Ring 1
9 Use 7017215 Ring, Back-up 1
10 Use 7017215 Ring, Retainer 1
11 Use 7017215 Seal 1
12 7017214 Nut, Spanner 1
13 Use 7017215 Wiper 1
14 0961977 Bushings 4
15 to 19 Not Used
20 7017215 Seal Kit (Includes Items 3, 4, 8-11 & 13) 1
