JLG 800A_AJ ANSI Parts Manual User Manual
Page 141
3120741
3-7
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
.
FIGURE 3-2. BOOM AND CYLINDER INSTALLATION - 800AJ
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
BOOMS AND CYLINDERS INSTALLATION
Ref
0257761
FRONT ENTRY PLATFORM
Ref
C
0272131
SIDE ENTRY PLATFORM
Ref
B
1
0801132
Boom Assembly -Tower (See TOWER BOOM ASSEMBLY
for Breakdown)
1
2
0801136
Boom Assembly - Main (See MAIN BOOM ASSEMBLIES
for Breakdown)
1
3
4845593
Upright Weldment
1
4
Rotator Actuator Assembly Options:
1
Use
1001103095
Front Entry Platform (was p/n 0060031) (See ROTATOR
ASSEMBLIES for Breakdown)
0060066
Side Entry Platform (See ROTATOR ASSEMBLIES for
Breakdown)
5
Not Used
6
4844816
Tube Weldment - Jib Top
1
7
4844817
Tube Weldment - Jib Bottom
2
8
4845716
Pivot Weldment
1
9
1683537
Lift Cylinder Assembly - Tower Boom (See CYLINDER
SECTION for Breakdown)
1
10
Use 1684497
Level Cylinder Assembly - Upright (See CYLINDER
SECTION for Breakdown) (was p/n 1683546)
1
11
1683547
Lift Cylinder Assembly - Main Boom (See CYLINDER
SECTION for Breakdown)
1
12
1683609
Lift Cylinder Assembly - Jib (See CYLINDER SECTION for
Breakdown)
1
13
Use 1684228
Slave Cylinder Assembly (See CYLINDER SECTION for
Breakdown) (was p/n 1683677)
1
14
1683682
Master Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
1
15
1120510
Cover, Upright
4
16
1670769
Cover, Cable
1
17
1670844
Cover, Upright
4
18
1670850
Cover, Tower Fly
1
19
0961947
Bearing, Garmax
AR
20
Pin Options:
1
3422558
Prior to SN 0300054012
3422860
SN 0300054012 to SN 0300069000
21
Pin Options:
2
3422559
Prior to SN 0300054012
3422861
SN 0300054012 to SN 0300069000
22
Pin Options:
1
3422560
Prior to SN 0300054012
3422867
SN 0300054012 to SN 0300069000
23
3422561
Pin
2
24
Pin Options:
1
Front Entry
3422563
Production (10-3/4in Length)
3422860
For Service Replacement Rotator (9-7/16in Length)
3422860
Side Entry Platform
