3120741 3-25
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
.
FIGURE 3-7. VALVE AND LIMIT SWITCH INSTALLATIONS (BOOM MOUNTED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0258217 BOOM VALVES AND LIMIT SWITCHES INSTALLATION Ref H
1 0100011 Compound, Locking AR
2 0100035 Compound, Locking AR
3 0630427 Bolt, Special 2
4 Bolt Options: 3
0641422 Bolt 1/4in-20NC x 2-3/4in (Prior to SN 0300048726)
3931436 Bolt 1/4in-20NC x 2-1/4in (SN 0300048726 to
SN 0300069000)
5 Bolt Options: 3
0641436 Bolt 1/4in-20NC x 4-1/2in (Prior to SN 0300048726)
3931464 Bolt 1/4in-20NC x 4in (SN 0300048726 to
SN 0300069000)
6 3310805 Locknut #8-32NC 4
7 3311405 Locknut 1/4in-20NC 6
8 3311801 Nut 1/2in-13NC 2
9 3520035 Plug, Cap 2
10 3570928 Plate, Spacer 2
11 3930824 Capscrew, Socket Head #8-32NC x 1-1/2in 4
12 Use 4360578 Switch, Limit (was p/n 4360322 & p/n 4360549) (Note: P/N
4360549 & P/N 4360578 does not include #13 Connector -
Purchase Separately) 2
13 Connector, Strain Relief Options: 2
4460428 Use with p/n 4360322 Switch
4460968 Use with p/n 4360549 & 4360578 Switches
14 Valve, Switch Options: 2
Use 4641136 Prior to SN 0300042387 (was p/n 4641045)
Use 4641136 SN 0300042387 to SN 0300049402 (was p/n 4641105)
4641136 SN 0300049402 to SN 0300069000
4641136 Replacement Parts:
14A 7011342 Valve, Check (1 per Assembly) 2
7011333 Seal Kit - Check Valve (1 per Assembly) 2
14B 7020172 Valve, Plunger (1 per Assembly) 2
7020173 Seal Kit - 7020172 Valve (1 per Assembly) 2
4641105 Replacement Parts:
14A See Note Valve, Check (1 per Assembly) (Note: Not Available
for Purchase.) 2
7020171 Seal Kit - Check Valve (1 per Assembly) 2
14B 7020172 Valve, Plunger (1 per Assembly) 2
7020173 Seal Kit - 7020172 Valve (1 per Assembly) 2
4641045 Replacement Parts:
14A 7020068 Valve, Check (1 per Assembly) 2
7020069 Seal Kit - 7020068 Valve (1 per Assembly) 2
14B 7020070 Valve, Plunger (1 per Assembly) 2
7020071 Seal Kit - 7020070 Valve (1 per Assembly) 2
15 4751400 Flatwasher 1/4in 6
16 4060805 Trim, Edge (SN 0300039755 to SN 0300069000 Only) 7in/25cm
17 3572606 Plate, Lower Boom Proximity Switch Target (SN 0300056439
to SN 0300069000) 1
