8-4 3120741
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
31 1703953 Decal - Warning/Crushing 3
32 1702862 Decal - JLG Lift 1
33 3820001 Rivet 4
34 3252347 Decal - Footswitch (Part of 4360031 Footswitch) 1
35 1703960 Decal - Max Tire Load 4
36 Decal - Fuel 1
1701542 Ford Engine Machines
1701505 Deutz Engine Machines
37 Decal - LPG Gas AR
Not Required Non-Dual Fuel Machines 0
1701543 Dual Fuel Machines 1
38 Decal - LP Gas Liquid Withdrawal System AR
Not Required Non-Dual Fuel Machines 0
1700818 Dual Fuel Machines 1
39 Not Used
40 Use 1001096141 Decal - Upright Level Override (was p/n 1702265) 1
41 1702903 Decal - Knob #1 1
42 1702927 Decal - Knob #2 1
43 1702924 Decal - Knob #3 1
44 to 47 Not Used
48 1704885 Decal - Website (SN 0300067900 to
SN 0300069000) 2
0258671 MANUAL STORAGE BOX INSTALLATION Ref A
101 0860520 Box, Manual Storage 1
1060279 Cable, Lanyard 1
0641408 Bolt 1/4in-20NC x 1in 1
0641406 Bolt 1/4in-20NC x 3/4in 1
4751400 Flatwasher 1/4in 6
3311405 Locknut 1/4in-20NC 5
0100011 Compound, Locking AR
TILT SENSOR INSTALLATION OPTIONS: Ref
1001091538 PRE ADE SYSTEM Ref E
1001093187 ADE SYSTEM Ref C
201 to 204 Not Used
205 1707110 Decal - Legend (Platform) 1
206 1707111 Decal - Platform Display 1
207 to 224 Not Used
225 1001096141 Decal - Upright Level Over Ride 1
226 to 227 Not Used
228 1001095809 Decal - Legend (MTB Control) 1
FIGURE 8-1. DECALS INSTALLATION - STANDARD (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
