JLG 800A_AJ ANSI Parts Manual User Manual
Page 277
3120741
7-29
SECTION 7
ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
BOOM CABLES INSTALLATION
Ref
0271374
800A
Ref
C
0271376
800AJ
Ref
1
0272429
800A (With 7500W Generator) (Sky Power)
Ref
A
0272431
800AJ (With 7500W Generator) (Sky Power)
Ref
1
201
Harness Assembly - Main Boom (12/4 -18/8)
Options:
1
4922575
800A
4922582
800AJ
1060896
Cable, Electrical - 4 #12 AWG, 8 #18 AWG & 1
STP #18 AWG
AR
201A
4460465
Socket, Female
11
201B
4460865
Connector - 19 Position
1
201C
4460509
Socket, Female
4
201D
4460473
Clamp. Cable
1
201E
4460466
Seal, Plug
8
201F
4460464
Pin, Male (16 Gauge)
11
201G
4460866
Connector - 19 Position
1
201H
4460508
Pin, Male (12 Gauge)
4
202
4922576
Harness Assembly - Tower Boom (12/4 - 18/8)
1
1060896
Cable, Electrical - 4 #12 AWG, 8 #18 AWG & 1
STP #18 AWG
44ft/13.4m
202A
4460465
Socket, Female
22
202B
4460865
Connector - 19 Position
2
202C
4460509
Socket, Female
8
202D
4460473
Clamp. Cable
2
202E
4460466
Seal, Plug
8
203
4922579
Harness Assembly - Tower Boom (18/2) (800A Only)
1
1060902
Cable, Electrical - 18/2
47ft/14.3m
203A
4460465
Socket, Female
2
4460891
Connector, Terminal - 2 Position
1
204
4922580
Harness Assembly - Main Boom (18/2) (800A Only)
1
1060902
Cable, Electrical - 18/2
27ft/8.2m
204A
4460464
Pin, Male
2
4460897
Plug, Terminal - 2 Position
1
205
4922577
Harness Assembly - Tower Boom (18/2)
1
206
Not Used
207
Harness Assembly - Main Boom Options:
1
4922215
800A (10/3)
4922216
800AJ (10/3)
4922773
800A (8/5) (With 7500W Generator) (Sky Power)
4922775
800AJ (8/5) (With 7500W Generator) (Sky Power)
208
Harness Assembly - Tower Boom Options:
1
4922217
(10/3)
4922774
(8/5) (With 7500W Generator) (Sky Power)
209
1320256
Clamp, Block (Not Shown-Located on back of T/T)
1
210
4922581
Harness Assembly (18/2) (800A Only)
1
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064432 TO
SN 0300069000)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
