JLG 800A_AJ ANSI Parts Manual - Manual (Page 163)

3120741 4-1
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
SECTION 4 PLATFORM
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
4-1 PLATFORM COMPONENTS INSTALLATION (FRONT ENRTY) . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-2 PLATFORM COMPONENTS INSTALLATION (SIDE ENTRY) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4-3 PLATFORM CONSOLE ASSEMBLY (PRIOR TO SN 0300064432). . . . . . . . . . . . . . . . . . . . . . 4-10
4-4 PLATFORM CONSOLE ASSEMBLIES (WITH ADE SYSTEM) (SN 0300064009 ONLY) . . . . . 4-16
4-5 PLATFORM CONSOLE ASSEMBLIES (WITH ADE SYSTEM) (SN 0300064432
TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
4-6 CONTROLLER ASSEMBLY (SWING AND LIFT) (PRIOR TO SN 0300064432) . . . . . . . . . . . 4-26
4-7 CONTROLLER ASSEMBLY (SWING AND LIFT) (WITH ADE SYSTEM)
(SN 0300064432 TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
4-8 CONTROLLER ASSEMBLY (DRIVE AND STEER) (PRIOR TO SN 0300064432) . . . . . . . . . . 4-32
4-9 CONTROLLER ASSEMBLY (DRIVE AND STEER) (WITH ADE SYSTEM)
(SN 0300064432 TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
4-10 SOFT TOUCH SYSTEM INSTALLATION (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
