3120741 7-33
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
704A 7022819 Plug, Male - 8 Position (Natural) 1
704B 4460871 Socket, Female 8
705 See Note Controller Harness/Circuit Board Assembly (Drive and
Steer) (Note: Not Available for Purchase.) 1
705A 7022825 Plug, Male - 8 Position (Black) 1
705B 4460871 Socket, Female 7
706 See Note Ford Engine Harness (For replacement parts refer to
Ford Engine dealer (Ford EFI Engine Machines) (Note:
Not Available for Purchase.) 1
7022134 Ford Engine Fuel Pump Harness (Not Shown) (Ford
EFI Engine Machines) 1
7023657 Ford Engine TPS Harness (Not Shown) (Ford EFI
Engine Machines) 1
707 See Note Dual Fuel Shut-Off Filter Harness (Note: Not Available
for Purchase.) 1
7023679 Electrical Connector Kit (Includes [1] 2 Position
Connector, 2 Pins & 2 Seals) 1
708 1001093256 Harness, Tilt Ref F
708A 2920129 Bulb 1
4120035 Socket, Light 1
708B 4460464 Pin, Male Deutsch (16 Gauge) 4
708C 4460871 Socket, Female 4
708D 4460894 Plug, Male - 6 Position 2
4460465 Socket, Female 8
4460892 Terminal, Buss Connector - 6 Position 2
708E 4460761 Connector, Female - 4 Position 1
4460227 Pin, Male 4
708F 4460909 Connector - 12 Position (Black) 1
4460915 Wedge Lock - 12 Position 1
4460928 Socket, Female 6
708G 4460908 Connector - 12 Position (Gray) 1
4460915 Wedge Lock - 12 Position 1
4460928 Socket, Female 5
708H 4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 3
708J 4922099 Cable, Can-Buss (Machines with Can Buss Engine
Controllers & Caterpillar Engine without Can Buss
Engine Controllers) AR
4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 6
4460539 Terminal, Plug - 3 Position 1
708K 4922099 Cable, Can-Buss (Machines without Can Buss
Engine Controllers) AR
4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 6
4460464 Pin, Male Deutsch (16 Gauge) 3
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064432 TO
SN 0300069000)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
