JLG 800A_AJ ANSI Parts Manual User Manual
Page 283
3120741
7-35
SECTION 7
ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
805E
Connector, Female Options:
1
4460134
110V GFI
4460701
220V GFI
4460960
With 7500W Generator (Sky Power)
805F
4921801
Harness-Receptacle Box to Boom
(SN 0300064432 to SN 0300065566)
1
1060494
Cable, Electrical - 12/3
18in/47cm
805G
Connector Options:
1
4460071
SN 0300064432 to SN 0300065566
4460051
SN 0300065566 to SN 0300069000
806
Generator Electrical Components
4933215
110V
Ref
1/A
4933216
220V
Ref
1/A
3990010
Diode - 6 Amp (Not Shown)
1
806A
4922641
Harness - On/Off Switch
1
806B
4922482
Harness - Powermite Control Box to Relay
1
807
4921829
Generator to Rear of Boom Harness (110V)
1
4921955
Generator to Rear of Boom Harness (220V)
1
Note: Harness used to connect AC at platform
harness to generator receptacle to power platform
receptacle.
Ref
1060494
Cable, Electrical - 12/3
6ft/1.8m
807A
4460205
Plug, Male (110V)
1
4460233
Plug, Male (220V)
1
807B
4460134
Receptacle, Female (110V)
1
4460701
Receptacle, Female (220V)
1
808
See Note
Lights Harness (Note: Not Available for Purchase.)
1
1060341
Cable, Electrical - 16/2
48ft/14.6m
808A
3740049
Relay 1
808B
4922643
Harness, Bag (Located at Ground Control Box) (Not
Shown)
1
809
2920140
Platform Worklights Harness (External) (Includes Light
and Wire Only)
2
2820035
Loom, Vinyl
9ft/2.8m
809A
4460598
Connector, Strain Relief
1
809B
4360232
Circuit Breaker, 15Amp
1
809C
4922498
Platform Worklights Harness (Internal)
1
809D
4460871
Socket, Female
3
810
See Note
Soft-Touch System Harness (Note: Not Available for
Purchase.)
1
810A
1060341
Cable, Electrical - 16/3
16ft/4.9m
810B
4460425
Connector, Strain Relief
1
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064432 TO
SN 0300069000)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
