13 Getting Started
WLA-AWCG User Manual

Remove the protective cover from the slot on the Wireless LAN card and
connect the end of the antenna adapter to the Wireless LAN card by inserting
it into the slot.

Figure 7: Attaching the antenna adapter to the Wireless LAN network card

Attaching the external antenna

Once the antenna adapter has been attached to the Wireless LAN network card,
you can attach an external antenna, increasing the range of the AirStation Pro. To
attach an external antenna follow these steps:

Ensure the antenna adapter is attached to the AirStation Pro.

Figure 8: Displaying the antenna adapter connector
